(2) Mounting instructions
LEF-5C or LEF-10C
CUT-OUT HOLE DIMENSIONS
CHASSIS
WOOD SCREW(4)
WALL
FRONT CASE
OPERATION PLATE
Be sure to peel off clear protection film.
T
8
-
1
/
8
"
(206)
i
Cut out a hole in the wall;
H: 8-1/8"
X
W: 5-3/4"(206 x
146mm), securing a space
of 1/8" (3mm) on the left
and right sides.
^5-3/4"
(146)
LEF-3C or LEF-1C
WOOD SCREW(4)
FRONT CASE
CHASSIS
%
OPERATION PLATE
Be sure to peel off clear
protection film.
Cut out a hole in the wall;
H: 6-1/8"
X
W: 3-3/4"
(155 X 96mm), securing a
space of 1/8" (3mm) on each
left and right side.
CUT-OUT HOLE
DIMENSIONS
6
-
1
/
8
"
(155)
L3-3/4J
risen
LE-C or LE-CN,
LE-B or LE-BN
FRONT CASE
WOOD SCREW(4)
OPERATION PLATE
Be sure to peel off clear
protection film.
Cut out a hole in the wall;
H: 6-1/8" xW: 3-3/4"
(155 X 96mm), securing a
space of 1/8" (3mm) on
each left and right side.
CUT-OUT HOLE
DIMENSIONS
6
-1/8"
(155)
^3-3/4:
LE-D
SINGLE-GANG BOX
LE-DA
STAINLESS COVER
LE-DL
MOUNTING
LE-DL UNIT BRACKET
-
5
-
