8 If you want to load
more washing:
(If the door is open for
more than three minutes,
the machine will "forget"
the preset program, and
you must re-enter the
program you want.)
Open the door.
The drum will stop auto­
matically. Close the door
to restart and press
the START
____
pushbutton. ^
START
STOP .
If you want to alter the program:
*Press START for three seconds.
This stops and cancels the program
that is running and you can then
set the new program that you want.
9 When the machine has
stopped:
• Remove the washing
• Clean the lint filter
• Turn off the main switch
Cleaning the lint filter
The lint filter must be cleaned
after each time the machine has
been used. If this is not dona
drying performance will suffer, as
insufficient air will pass through
the drum. The machine may also
overheat: this will cause it to stop
utomatically.
Clean the filter as follows;
1. Grasp the filter holder by the
two holes near the center and
pull it off the peg on which it is
supported in the front door.
2. Take the filter out of the holdei
and brush away the lint in it by
hand.
NOTE; Wear and tear of fabrics
in a tumble dryer is insignificant.
The lint caught in the lint filter is
dust and fiber residue that has
been formed when the garments
have been used.
3. Replace the filter in the holder
and refit the holder in position on
the peg in the door.
Note! Clean lint collecting near the tumble
dryer as it can be sucked into the
air intake.
NOTE:
When you start the dryer for the first
time, a slight rumbling may be heard
during a short warming-up period. When
the dryer is run-in, this sound will
disappear.
If the machine
does not work
The machine will not start
Check that:
* The front door is properly closed.
* The main On/Off pushbutton is pressed in.
* You have set the required program or the required time
correctly.
* The electric plug is firmly inserted in its socket.
* All fuses are intact.
H the machine still fails to start, it is probable that the
automatic safety cutout has operated, h disconnects the
power supply to the machine if the internal temperature
rises excessively, i.e. if the lint filter is blocked by dust.
Start by cleaning the filter, emptying the water container
and cleaning the condenser. Reset the cutout by pressing
the button on the back of the machine.
Excessive drying time
Check that the lint filter is not blocked. Excessive drying
times can also be caused by the machine being installed in
a very small space and by the air in the room (which cools
the machine) becoming too warm. Make sure that the
machine has a plentiful supply of cool air. Do not overload
the dryer. Hems to be tumble-dried must first have been
spin-dried, preferably at 800 r/min or more.
Fauit indication
The display window that shows the number of hours of
delayed start can also display fault message:
F2 - When the machine has run lor a maximum time of 3
hours, it will stop automatically. Check that the fuse
is intact. This fault indication can be indicating when
running a small terry load. Always use Timed
Program or Automatic Program Damp Dry by this
type of load.
F3 - This indicates an electric fauH. Phone for service.
F4 - Indicates a clogged fluff fiHer. This code will appear
after the program has finished. Be sure to remove
fluff fiHer and clean before running the next load of
clothes.
F5 - Indicates a fauH whh the moisture sensor. Call for an
Authorized Asko Service Agent.
