Resetting the Module (without the plug-in valet)
WARNING! By resetting the module, all programmed values are erased — i.e.: tach, transmitter as well
as programming options. The programming options are returned to their default values.
1.
FLASH the hood pin (see on page 1).
2.
In ten seconds or less, press and release the brake pedal 6 times.
The parking lights will flash 8 times confirming the reset.
Transmitter Programming Procedure.
1.
FLASH the hood pin {see on page 1)—the parking lights will stay on for up to 20 seconds.
2.
Before the lights go out, turn the ignition key to the
IGNITION ON (RUN) position and immediately to the OFF position.
3.
Press and hold the “I” button and keep it down until the parking lights flash 5 times quickly.
4.
The transmitter has been stored in memory.
5.
To exit: close the hood.
Entering Programming Options
Flash the hood pin switch {see on page 1) — the parking lights will stay on for up to 20 seconds.
Before the lights go out, press and hold the brake pedal and then press one of the following buttons:
Button
I
........................................ to access mode 1; or
Button
II...................................
to access mode 2
The parking lights will flash and the horn will honk (if programmed) once or twice to confirm entry into a mode.
Release the brake pedal.
BUTTON
I
for
Option 1,
BUTTON n
for
Option 2,
BUTTON
I & II
for
Option 3.
Programming Options
MODE 1
”
INDICATES DEFAULT SETTING
FUNCTION 1 - Ignition-controlled door locks
OPTION 1*
Ignition-controlled door locks disabled
OPTION 2
Ignition-controlled door locks enabled
FUNCTION 2 - Secure Lock
OPTION 1*
Secure lock disabled
OPTION 2
Standard secure locks enable
FUNCTION 3 - Passive / Active Arming of the starter kill
OPTION 1*
Starter Kill passive (1-minute timeout.)
OPTION 2
Starter Kill active
OPTION 3
Starter Kill passive {1-minute timeout). Press the I button to unlock.
FUNCTION 4 - Lock Pulse Duration
OPTION 1*
7/10-second lock / unlock pulses
OPTION 2
4-second lock ñ unlock pulses
OPTION 3
7/10-second lock pulse and two d-second unlock pulses
FUNCTION 5 - Flashing LED
OPTION 1*
Enabled (without starter kill ^ will flash only when ignition is OFF)
OPTION 2
Disabled
OPTION 3
Enabled {with starter kill will flash when the starter kill engages.
This option should be selected ONLY if the starter kill is installed.)
Installation Guide
Diagnostics - Parking Light Fiash Tabie
Flashes
Description
1
•
Doors locked, starter kill armed.
•
Run time has expired.
•
Buttons I & II pressed (TRUNK).
•
Start signal received by the module.
•
Cold weather mode cancelled.
2
• Remote start attempt cancelled by remote.
• Doors unlocked, starter kill disarmed.
• Exiting ignition valet
• Power-up reset
3
• Entering cold weather mode.
• Entering ignition valet.
3 slow flashes^
>after a failed start attempt | The module did not detect a tach signal.
4
♦ +12 V detected on the brake input wire either while cranking or during run time.
♦ Entering multi-speed tach programming.
5 Slow
• Start attempt failed because no tach signal has been programmed.
5 Fast
• Tach signal programmed.
6
• A remote start was attempted while a tach-before-crank signal was detected before cranking.
8
• Unit reset see “Resetting the Module” (p.2)
10
• A ground (-) signal was detected on the hood pin input wire.
1 —pause —
1—pause—
5 flashes
[During the
transmitter
programming
procedure]
♦ Transmitter has been programmed.
1 - pause - 2
♦ There was a remote start attempt while the vehicle was in valet mode.
• Failed start: vehicle’s low battery voltage.
ON SOLID for 3
seconds>.
^followed by 1 flash
Exiting cold weather mode
^followed by 3 flashes
Entering cold weather mode
ON continuously
• Idle mode: Idle mode is engaged
♦ Run time: The vehicle has been remote started and is in runtime.
ON continuously
While the brake
pedal is
pressed.
• Confirms that cold weather mode is engaged
ON 2 seconds
• The hood has been opened and a ground (-) signal has been detected on the hood pin input
wire.
ON 4 seconds
• Locking or unlocking a door (with Door pulses configured to 4 sec.)
ON 20 seconds
♦ The hood pin has been flashed and you are now in the programming centre.
Constantly flashing
up to 25 seconds
♦ Panic Mode is triggered.
