Cleaning the Magic Filter
1. Push the upper part 2. Open the cover as
of the filter and pull in. shown in the figure.
3. Clean the filter. 4. Close the cover and insert the lower
part of the filter in the basket first and then
push the filter until your hear a "click" sound
Water Connection
For normal kitchen-sink tap only use the inlet hose with cold water inlet.
Connect the inlet hose to the male hose thread adapter by turning it clockwise to be fixed tightly.
Make sure to insert the rubber ring enclosed. Then connect tightly to your sink.
Note : Some faucets may require you to also use the female hose thread adapter between the male
adapter and your sink as shown below. Make sure the rubber ring is inserted and connect to
your sink.
Only necessary on some faucets.
Male Adapter
Rubber Ring
Inlet hose
Female Hose Thread Adapter
Rubber Ring
Male Adapter
Rubber Ring
Inlet hose
Connecting The Water Supply Hoses
1. Your washer is provided with dual water inlets {hot & cold)
Connect the water supply hose to the water tap.
Fasten it tightly.
2. Next, connect the other end of the water supply hose
to the inlet valve at the back of the washer.
Screw the hose clockwise all the way in.
3. When using as a portable washer connect hose to
the cold side of the water valve.
Note:
Be sure to connect the hot inlet hose to hot water tap and hot water valve. For best operating
conditions your hot water should be approximately 50®C {122*F) otherwise water above this
tempeialuie will cause damage to the machine.____________________________________________
Turn on the water completely to check for any leakage.
If any, turn off the water and try again above procedures.
For special tap, use connectors provided or call a qualified plumber for the installation.
