www.desatech.com 21 107902-01K
PARTS LIST
This list contains replaceable parts used in your heater. When ordering parts, follow the instructions
listed under Replacement Parts on page 22 of this manual.
KEY
NO. PART NO.
DESCRIPTION QTY.
1 09304-01 Screw, #10 x 3/" • • 2
2 099467-07 Front Panel Assembly • • 1
3 09931-03 Grill Guard • • 1
4 10110-01 Grill Guard Clip • • 2
5 099469-02 Reflector Assembly • • 1
6 099059-03 ODS/Pilot Assembly • 1
503329 ODS/Pilot Assembly • 1
6-1 09514-01 Thermocouple • • 1
6-2 09594-01 Ignitor Electrode • • 1
7 0994-02 Burner Assembly • • 1
099056-01 Injector • 2
099056-06 Injector • 2
9 099390-02 Tubing - Valve to Plaque A • • 1
10 09937-17 Pilot Tubing - Valve to Pilot • • 1
11 099392-01 Tubing - Valve to Plaque B • • 1
12 099391-02 Tubing - Regulator to Valve • • 1
13 100432-01 Control Valve • • 1
14 ** Cabinet Assembly • • 1
15 099415-1 Gas Regulator • 1
099415-17 Gas Regulator • 1
16 0950-01 Valve Retainer Nut • • 1
17 099393-02 Control Knob • • 1
1 0991-01 Internal Tooth Washer • • 1
19 097159-04 Piezo Ignitor • • 1
20 09271-03 Ignitor Cable • • 1
PARTS AvAILABLE - NOT SHOWN
100642-02 Assembly, Hardware • • 1
099395-07 Control Position Decal • • 1
116360-01 Lighting/Warning Tag (English) • • 1
116360-02 Lighting/Warning Tag (Spanish) • • 1
** Not a field replaceable part.
GWRP10 GWRN10
