Autostart Two-way 6-Button LCD Automatic Transmission Remote Starter User - Manual (Page 7)

• Within 3 seconds, press the BHand ~ buttons simultaneously until the parking lights go out
To take the system out of home valet mode:
• Turn the ignition key to the ignition o n ( run ) position.
The system will warn you if someone attempts to start your vehicle while it stands in home valet
mode. The parking lights will:
1- Turn ON then o ff ; then
2- Flash twice, pause; then
3- Flash twice again.
How to Access Home Valet^^ Mode
Function By pressing Icon Sound Instructions / description
To enter home
valet™ mode
step 1: orkJ
step 2:
simultaneously
within 5 sec.
m
1 beep
Press or i*Jl
Within 5 seconds, press
l^3l+ ^ the transmitter will
Higplayl V 1 and there will be 1
beep.
To exit home valet
™ mode
None None None
Insert key in ignition switch and
turn to the on position. The icon
will disappear.
Turbo Mode
If turbo mode is configured at installation, it will allow a turbocharger to idle down after the user
leaves the vehicle: the unit will take over the vehicle and keep it running for 60 seconds (or until it
is shut down by remote control), then shut down the engine.
Proceed as follows to set the system to Turbo Mode:
1. With the engine already running, press the button on the transmitter until the parking lights
come ON.
2. Remove the ignition key from the ignition switch. The engine will go on running.
3. Exit the vehicle and close the door.
4. Press the li button to lock the doors; the engine will shut down after 60 seconds of Turbo
Mode.
Engine Run Time
If you have a gas engine, your remote starter can be programmed to run the engine for 3, 15, or
25 minutes (15 minutes by default). If you have a diesel engine, the remote starter can be
programmed to run the engine for 8,20, or 30 minutes (20 minutes default).
How to Access to Runtime Status (Indication purpose only)
Function By pressing Icon Gasoline Diesel
Engine runtime
+ 3 minutes 8 minutes
+ 15 minutes 20 minutes
1 25 minutes 30 minutes
Temperature Request (If ACC-Temp-100 instaiied)
The user can request the temperature in the vehicle if a Temperature Sensor Module (ACC-Temp-
100) is installed:
o Press the
m
button for 1 second and release; you will hear a beep. L-01 will appear
on the screen.
o Immediately press the li button and hold it until the temperature is displayed on the
LCD screen.
P. 10 User Guide
- The El icon will disappear from your LCD remote.
Note : With the remote valet activated, the remote starter will be disabled.
Panic Mode
In an emergency situation, you can activate panic mode by pressing and holding the
IE
button for
3 seconds. If the vehicle is under a remote start, the engine will shutdown automatically before
setting off the horn. You can stop the horn by pressing S (this will lock your doors) or by
pressing S (this will unlock your doors).
If the car is not running, you can stop the horn by pressing the m or H buttons but it will not lock
or unlock the doors.
Furthermore, the panic mode can be stop by activating one of the following three (3) features:
a) Remote valet (pressing S and ^ for 3 seconds)
b) Ignition valet (turning the key inside the ignition switch from off to on 5 times in a row)
c) By pressing the valet switch (if included).
Panic mode will automatically shut down after 25 sec.
Note: Panic mode can only be activated if the horn has been adequately configured by
your installer.
Quick Lockout TM
(Also called secure panic .) For fast protection in emergency situations, the system will lo ck all
doors when you press the brake pedal while you hear the sound signal . ( Quick lockout is only
available when panic mode has been set off.)
Cold Weather Mode
When cold weather mode is active, the engine starts every 2 hours and runs for 3 minutes (or for 8
or 20 minutes with diesel engines). Cold weather mode automatically ends after 24 hours.
To enter Cold Weather Mode:
Press and release the
[E
button until you hear a beep. Release the
E
button,
5
0
i
will appear,
then press and hold the ^ button for 3 seconds until the parking lights flash three times.
The remote control will beep once and the ( 3 icon will appear on the display.
To exit Cold Weather Mode, do any one of the following actions:
• Open the hood.
• Start the engine by remote.
• Turn the ignition key to the ignition o n ( run ) position.
• Press
thelE
button until you hear a beep. Release the
E
button and S D i will appear on the
display. Then press the ^ button for 3 seconds (the parking lights will flash once).
When the system exits cold weather mode, the remote control will beep once and the (^icon will
disappear.
To verify whether the system is in cold weather mode:
Press the brake pedal: If the vehicle is in cold weather mode, the parking lights will stay on while
the pedal is pressed.
How to access cold weather mode
Function Button pressed Icon Sound Instructions /description
To enter cold
weather mode
mA
Beep Press E and the press and
To exit cold weather
mode
mA
None Beep hold ^ for 3 seconds.
User Guide P. 7
