41
Specification
Specifications are subject to change without notice. Mass and dimension are approximate.
General. Power supply: 12V DC
Current consumption/Fuse: 8A/ 10A & 1A
Maximum power output: 50Wx4 channels
Dimensions (W x H x D) 178 x 51 x 178 mm
Working temperature range: -20º - +60º
FM Stereo Radio. Frequency range: 87.5 - 108.0 MHz
Usable sensitivity/ I.F. Frequency: 3 uV/ 10.7 MHz
MW Section. Frequency range: 522 kHz-1620 kHz
DVD Deck Specification Format DVD/SVCD/VCD/MP4/MP3/WMA/CD/HDCD/DVD
Audio/MPEG4/DivX/Picture-CD/Photo-CD/CD-R/CD-RW/DVD±R/JPEG
Video System/ Audio System Standard NTSC/PAL / 24 bit/96 KHz
Loading System Auto Loading
Mounting Angle 0 to +/-30
Video Specification
Video System 16:9 and 4:3
Video Output level 1.0Vp-p 75 ohms
Horizontal Resolution 500
Audio Specification
Maximum Output 2Vrms(+/-3dB)
Frequency Response 20 to 20KHz
S/N Ratio(A-vtd)/ Separation 60dB/ 50dB
Line out. Output: CD max 2000 mV
