Airless Paint Sprayers

1

Operating Instructions and Assembly Instructions

Specifications

Operating Pressure

model A - D Power
ratings

model E & F Power
ratings

Safety Features

0-3000 psi

115 Volts AC

220 - 240 Volts AC

Spray gun trigger lock

60 Hz

50 Hz

Spray gun trigger guard

8.5 Amps

4.6 Amps

Spray gun pressure diffuser
Prime/Spray valve over
pressure relief

model

weight
(lbs.)

Capacity (GPm)

maximum
hose length

maximum
Tip Size

@ 0 psi

@ 2000 psi

PS2###B/E

49 *

.42

.26

100 ft.

.015 in.

PS2###C/F

55 *

.50

.31

150 ft.

.017 in.

PS2###D

55 *

.60

.43

200 ft.

.019 in.

* Weight does not include mounting

model

motor kit

housing kit

Diaphragm
kit

Eccentric /
bearing

Pressure
valve kit

PS###B

MC014500SV

AL133509SV

AL125905SV

AL116200SV

AL131401SV

PS###C

MC014502SV

AL133509SV

AL125906SV

AL116201SV

AL131401SV

PS###D

MC014503SV

AL173304SV

AL173700SV

AL116204SV

AL131403SV

PS###E

MC014520SV

AL133509SV

AL125905SV

AL116200SV

AL131401SV

PS###F

MC014521SV

AL133509SV

AL125906SV

AL116201SV

AL131401SV

NOTE: All check valve components come with the diaphragm kits.
