A-4
Vibrato Rate
NRPN MSB = 01H
NRPN LSB = 08H
Data Entry MSB = mmH
mm .. Vibrato Rate = 00H to 40H to 7FH (-64 to 0 to +63)
Recognition
When the instrument receives this message, the preset
Vibrato Rate value for the tone is changed to the Vibrato
Rate value that corresponds to the data entry MSB of the
received message. There is no change when the value of
the data entry MSB is 40H(0).
Vibrato Depth
NRPN MSB = 01H
NRPN LSB = 09H
Data Entry MSB = mmH
mm .. Vibrato Depth = 00H to 40H to 7FH (-64 to 0 to
+63)
Recognition
When the instrument receives this message, the preset
Vibrato Depth value for the tone is changed to the value
that corresponds to the data entry MSB of the received
message. There is no change when the value of the data
entry MSB is 40H(0).
Vibrato Delay
NRPN MSB = 01H
NRPN LSB = 0AH
Data Entry MSB = mmH
mm .. Vibrato Delay = 00H to 40H to 7FH (-64 to 0 to +63)
Recognition
When the instrument receives this message, the preset
Vibrato Delay value for the tone is changed to the value
that corresponds to the data entry MSB of the received
message. There is no change when the value of the data
entry MSB is 40H(0).
Byte 1 Byte 2 Byte 3
BnH 5BH vvH
n ....... Voice Channel Number = 0H to FH (Ch1 to Ch16)
vv .... Reverb Send Level = 00H to 7FH
Effect 3 Depth (Chorus Send Level)
Format
Byte 1 Byte 2 Byte 3
BnH 5DH vvH
Byte 1 Byte 2 Byte 3
BnH 63H pmH (MSB)
BnH 62H plH (LSB)
Byte 1 Byte 2 Byte 3
BnH 54H kkH
n ....... Voice Channel Number = 0H to FH (Ch1 to Ch16)
kk .... Source Note Number = 00H to 7FH
Effect 1 Depth (Reverb Send Level)
Format
NRPN MSB NRPN LSB Parameter
01H 08H Vibrato Rate
01H 09H Vibrato Depth
01H 0AH Vibrato Delay
01H 20H TVF Cut Off Frequency
01H 21H TVF Resonance
01H 63H TVF/TVA Envelope Attack Time
01H 64H TVF/TVA Envelope Decay Time
01H 66H TVF/TVA Envelope Release Time
See “Vibrato Rate” through “TVF/TVA Envelope Release
Time” for the data entry MSB value range and other details.
NRPN (Non-Registered Parameter Numbers) ★
With the instrument, NRPN are defined as tone editing pa-
rameters and drawbar parameters. The MSB and LSB of an
NRPN specify the parameter being controlled, while the spec-
ified parameter’s value is set in accordance with the subse-
quent data entry.
The following table shows the relationship between parame-
ters and NRPN as defined by the instrument.
n ....... Voice Channel Number = 0H to FH (Ch1 to Ch16)
vv .... Chorus Send Level = 00H to 7FH
n ....... Voice Channel Number = 0H to FH (Ch1 to Ch16)
pm ... MSB of NRPN
pl ..... LSB of NRPN
Recognition
• NRPN messages not defined by the instrument can also
be received, but subsequent data entry values after
undefined NRPN messages are ignored.
• After the NRPN MSB and LSB are received and the
applicable control parameters settings are made, the
value is set by receipt of the MSB of the subsequent
data entry. The data entry LSB is ignored.
427B-E-068B
Byte 1 Byte 2 Byte 3
BnH 4AH vvH
n ....... Voice Channel Number = 0H to FH (Ch1 to Ch16)
vv .... Filter Cutoff Frequency = 00H to 7FH
Portamento Control ★
Format
Brightness ★
Format
Format
