603EBL (Event) & 603CLBL (CUM Split)
STOPWATCH INSTRUCTIONS___________
Buttons: T (top) Slide L (left) R (right)
Back Light
Slide ON-Turns LED backlights ON
Slide "down"-Turns LEDs OFF
Event & Time-Out/Time-ln
T-Start
T-Stop
T-Restart
T-Stop
L-Reset
(time out)
(time in)
SPLIT TIMING (603CL only)
Select CUM or LAP Split Mode
R-Select
("CUM" or "LAP" in display)
CUM or LAP Split Timing
T-Start -
(Running Split Time)
L^Split
(Split 1)
L-Release
(Running Split 2)
L-Split*
(Split 2)
L-Release
(Running Split 3)
T-Stop
(Last Split)
L-Reset**
(Resets to 0:00.00)
•Repeat Split & Split Release for each Split
**lf last Split was not Released, Press again to Reset
1-2 Fast Finish in CUM Mode
T-Start
(Running CUM Time)
L-Split
(Display Finish #i)
T-Stop
(Capture Finish #2)
L-Release
(Display finish #2)
L-Reset
(Reset to 0:00.00)
BATTERY INSTRUCTIONS
Battery Type & Life:1-AA Stopwatch life is 18 months
2-AA Backlight life is 24 hours continuous use
Change Batteries & TesLRemove back & replace 1 or 2 batteries.
Replace the back, bottom first and bow the top to insert tabs at top.
Test BL for proper battery insertion.
PERFORMANCE SPECIFICATIONS
Performance Functions
*10 Hour Display Range, with Rollover
*1/100 Sec Resolution
*Lap Split timing (603 CL only)
*Cum Split Timing (603 CL only)
*1-2 Fast Finish Timing (603 CLoniy)
*Time-Out/Time-ln Timing
Performance Features
*XL Display
*5-Year, No-Proof-of-Purchase Warranty
*Shock Resistant
*32,768Hz Quartz Crystal to 0.01 sec/hr accuracy
‘Accurate Temp 5°C-35°C(41°F-95°F)
•Operating Temp: -10°C -60°C(14°F-140°F)
USER REGISTRATION
Please return this USER(not owner)Registrafion (ora copy)
to the Repair Center address on the warranty label,
so that we may keep you informed of future developments.
Mostcommou use?_
Model #C603
Telephone (optional).
USER______________
■ ZIP-
NO-PROOF-OF-PURCH ASE LIMITED WARRANTY
See label on back of unit for details, or check
ACCUSPLIT, Inc., 6120 Stoneridge Mall Rd., Suite 210
Pleasanton, CA 94588 USA
800-965-2008 • 925-226-0888 • FAX 925-463-0147
WWW.
ACCIJSPl JT.com • [email protected]
