BLANCO
FAUCET SPECIFICATIONS
Contemporary Bar Faucets
BLANCOQUADRIS™ Single Lever
Model 157-180
FEATURED MODEL
157-180-ST
BLANCOQUADRIS™ Single Lever in
Solid Stainless Steel
Please note: the Quadris stainless steel model teatuies real stainless
steel (AISI304).
ADDITIONAL MODELS
157-180-CR Polished Chrome
FEATURES
• Solid brass body (chrome)
• Solid stainless steel (AISI 304)
• Ceramic disc cartridge
• Color coded hot & cold supply lines
• Maximum 2.2 G.P.M. flow rate
• Installation In a 1-3/8" hole
CODE/STANDARDS COMPLIANCE
ASMEA112.18.1-2005
NSF 61 Certified In conformance to the Uniform
Plumbing Code (UPC)
WARRANTY
Blanco America’s Bar faucets feature a LIMITED
LIFETIME WARRANTY to be free of all manufacturing
defects under normal use. See our complete warranty
for details.
While Blanco America endeavors to provide accurate
Information, all dimensions are nominal, cannot be
guaranteed, and are subject to change or cancellation.
Blanco America assumes no responsibility for use of
superseded or voided specifications.
PRDDUCT SPECIFICATION
Bar faucet to include lever handle with solid
stainless steel body and ceramic disc cartridge.
Faucet dimensions to be as follows: Reach: 7";
Spout Height: 6-1/4", and Faucet Height: 7-3/4".
Hot and cold supply lines to be color coded.
Bar faucet to be BLANCOQUADRIS™, Model
157-180-____ in___________________^finish.
Polished Chrome 157-180-CR
Solid Stainless Steel 157-180-ST
MODEL 157-180
NOMINAL DIMENSIONS
SPOUT
FAUCET
MODEL
REACH
HEIGHT
HEIGHT
157-180
7
6-1/4
7-3/4
JOB INFORMATION
Job Name:__________
Contact:
See next page for exploded parts drawing and parts list.
Date Specified:
Specifier:______
Contractor:
BLANCO AMERICA
800.451.5782
© 2008 BLANCO AMERICA 06/08
SPEC-003
