4 .
OPERATION
CARE IN DRILLING
Twist drills are brittle and will break if enough bending stress is applied. To avoid
stress on the drill bit, try extending your index finger along the side of the drill*
housing V ith your middle finger on the trigger. Remember guide the tool, don’t
force it! Should the tool become overheated., run it free of any load at maximum
speed. The drill will cool faster by running it without toad.
DRILLING IN METAL
Use a cutting lubricant when drilling metals. The exceptions are cast iron and brass
whi'-h should be drilled dry. The cutting lubricant that works best is sulphurized
cutting oil. Aluminum is best drilled with kerosene.
DRILLING IN WOOD
Holes In wood can be made with the same twist drills used for metal. These bits
may overheat unless pulled out frequently to clear
Chios from the flutes» For
larger holes, use Power Drill Wood Bits with a shank size that will fit your drill's
chuck. Work that is apt to splinter should be backed up with a block of wood. Let
up on the pressure just before the tip cuts through, this will give a good clean hole.
ACCESSORIES
Recommended accessories for use with your Drill are shown below and in
Black & Decker catalogs
(CAUTION: The use of any other accessory or
attachment might be hazardous.) For safety in use, the following acces­
sories should -be used only in the sizes specified below:
BITS, METAL DRILLING - Up to V*" with 1 / 4 " DRILL, up to with Vs" DRILL.
BITS, MASONRY DRILLING - Up to ^ 2 ".
BITS. WOOD DRILLING - Up to Vs" with V 4 " DRILL: up to 3 / 4 " with Vg" DRILL.
HOLE SAWS — Up to I Vs" with Vr DRILL: up to IV 2 " with DRILL.
WIRE BRUSHES— Up to 3" diam. GRINDING WHEELS — Up to 2" diam.
BUFFING WHEELS - Uo to 4" diameter.
BACKING PADS - 4 % " diameter. SANDING DISCS & POLISHING BONNETS up to
5" diameter.
We strongly recommend that your first curchase be the No. U-2106 Safety Glasses
which should be worn when using all drill accessories.
ÛJ
L y
--- □------ -
I
1 ,,
Ti :ij
1 II
j| i!'
HOLE SAWS will cut
larger diameter holes in
wood up to 3 / 4 " thick.
WIRE CUP BRUSH re­
moves rust, scale, and
old paint from metal
surfaces.
TT
SHAPING SET includes
3 cutters—bevel, bead­
ing and corner round.
PAINT
POLISHING BONNETS.
For cleaning, polishing,
waxing of cars, floors,
etc.
DRILL BIT SHARPENER
enables you to extend
the useful life of your
drill bits.
SAFETY GLASSES (No. U2106).
Lightweight, clear plastic with
side shields. Wear alone or over
regular glasses.
PAINT MIXER. Thorough­
ly mixes paint in up to
1-gal. cans. Fast, easy.
CAUTION;
Keep paint
and thinners off of drill
to prevent serious dam­
age to plastic.
