PARTS LIST
Assembly Instructions for
“PRESTIGE” Draft Chair No. DC310
Kty
UTY DUSCKIHI ION
KtY
QTY
DESCKIHIIÜN
KfcY QTY Ut SCRIPT ION
1
5
CASTER
7
1
BACKREST
12
1
PLASTIC HOLDER
2
1
BASE
8
1
PLASTIC COVER
13
1
SEAT
3
1
SEAT POST
9
2
BACKREST SCREW
14
1
MECHANISM
4
1
FOOTRING
10
1
STEEL PLATE
15
6
MECHANISM SCREW
5
1
KNOB FOR FOOTRING
11
1
BACKREST POST +
18
1
KNOB FOR UP & DPWN
8
1
PLASTIC BELLOW
1 PLASTIC COVER
17
1
PLASTIC STOPPER
STEP 1.
STEP 4.
PREVENTIVE MAINTENANCE AND WARNINQ
• UH TH» PRODUCT ONLY FOR SEATWO ONE PERSON AT A TBK.
• DO NOT use CHAIR A8 STEP ITOOUADDER.
• DO NOT USE CHAIR UNLESS ALL BOLTS. SCREWS AND KNOBS ARB TKIHT, AT LEAST EVERY SIX MONTHS,
CHECK ALL BOLTS, SCREWS AND KNOBS TO BS BURS THEY ARE TIGHT.
• IP ANY PARTS ARE HffiSINO, BROKEN, OAMAOtO OR WORN, STOP USE OP THE PRODUCT UNTIL REPAIRS
ARE MADE USWO PACTORY AUTHORIZED PARTS.
• PARURE TO FOLLOW THESE WARNIN08 CAN RESULT TO SERIOUB INJURY.
Alvin & Company, Inc. Bloomfield, Ct Grand Prairie, TX Rancho Cordova, CA
