CK2.27CK1.1
B&K Programmable Keypad
TM
*B&K
IN 6
IN I
IN 7
IN 2
IN 8
IN 3
IN 9
IN 4
FM
IN 5
PAGE 1
"One Touch Operation In Every Room Of Your Home"
The CK 2.2 keypad provides power to control up to 50 components and the ability to
program
over
1500
infrared
commands
and
macros.
The
CK
2.2
supports
importing
devices and remote control files from most Universal Remote Control and B&K keypads
or remotes. The CK 2.2 has both RJ-45 and terminal block connections on the back panel
for easy connectivity and daisy chaining. The CK 2.2 also has a programmable, 256-color
capable LCD display. Choose a backlight color for the entire keypad or customize a back
light color for each device.
The CK1.1 keypad is B &K's answer to a single gang, wall mounted user interface. The
CK1.1
keypad
provides
5
programmable
hard
buttons
and
up
to
4
pages
of
20
programmable buttons (5 programmable buttons per page). The CK1.1 keypad stores IR
source
codes
from
the
expansive
database
built
in
to
the
PC-based
software.
Each
keypad is able to retain memory for up to 10 years with no power supply, using our smart
memory backup system.
Programmable Backlit LCD Display
Programmable Macro Capability
Software Updates Via an Internet Connection
Large IR Database for use with Other Manufacturers' Source Gear
Learning Capability
IR Pass-Through Sensor on Front Panel
RJ-45 on Back Panel for Easy Connectivity and Daisy Chaining
Simple ideas executed properly with a touch of ingenuity produces great results.With an
expansive IR database built into the PC based software, B&K has the codes to control
almost any IR device. With the touch of a button, sit back and enjoy the ease and
elegance of complete control by B & K.
Flexible
The CK2.2 Keypad and
CK1.1
Keypad
support
importing
devices
and
remote
control
files
from
most
Universal
Remote Control and B&K
keypads or remotes.
Simple Installation
The CK2.2 Keypad and
CK1.1 keypad have RJ-45
and terminal block connec
tions on the back panel for
easy connectivity and daisy
chaining.
Customize
The CK2.2 has a program
mable, 256-color capable
LCD display. Choose a back
light color for the entire
keypad or customize a back
light color for each device.
B&K
S
imply
B
etter
!
B & K C o m p o n e n t s L i m i t e d | B u f f a l o , N e w Y o r k | | 8 0 0 . 5 4 3 . 5 2 5 2 | 7 1 6 . 6 5 6 . 0 0 2 3
