SKU 98332 For technical questions, please call 1-800-444-3353. Page 9
Functions
When used with an appropriate sol- 1.
vent (not included) this Parts Washer
is useful for cleaning mechanical
parts of dirt, grease and other con-
taminants.
When activated, the pump directs a
2.
stream of solvent into the Body (7).
The solvent is recirculated through
the Screen (17) and back into the
Body.
The solvent may be reused many
3.
times until it has become too dirty
and must be replaced.
This tool includes a wash tub shaped
4.
Body (7), Work Shelf (6) and Work
Basket (2). For holding, sorting or
soaking parts.
The Cover (1) may be lowered to
5.
close the tool when not in use.
A fusible link in the Safety Plate (5)
6.
will melt in the case of fire, shutting
the Cover (1) and suffocating the fire.
oPeratinG instructions
read the entire imPortant
saFetY inFormation
section at the beginning of this
manual including all text under
subheadings therein before set
up or use of this product.
tool set up
to PreVent
serious injurY
From accidental
oPeration:
turn the Power switch of the
tool to its “oFF” position and
unplug the tool from its
electrical outlet before
performing any inspection,
maintenance, or cleaning
procedures.
Prior to use, the tool must be filled 1.
with up to 20 gallons of suitable
solvent (not included). Appropriate
solvents are available from Harbor
Freight Tools.
Work Piece and Work area set up
Designate a work area that is clean 1.
and well-lit. The work area must not
allow access by children or pets to
prevent injury and distraction.
Route the power cord along a safe
2.
route to reach the work area without
creating a tripping hazard or exposing
the power cord to possible damage.
The power cord must reach the work
area with enough extra length to al-
low free movement while working.
There must not be hazardous ob-
3.
jects, such as utility lines or foreign
objects, nearby that will present a
hazard while working.
Safety goggles or face shield, rub-
4.
berized gloves, apron, floor mat and
other safety equipment must be pro-
vided to the operator for safe opera-
tion of this tool.
