1.
FLASH
the hood pin {see on page 1)—the parking lights will stay on for up to 20 seconds.
2.
Before the lights go out, turn the ignition key to the IGNITION ON (RUN) position and immediately to the OFF position.
3.
Press and hold the LOCK button and keep it down until the parking lights flash 5 times quickly.
4.
The transmitter in its memory.
5.
To exit: close the hood.
Transmitter Programming Procedure.
To program a transmitter
on the second vehicle for multi-car operation, you must press the TRUNK button (instead of LOCK or
UNLOCK) in step 3 of the transmitter programming procedure:
Entering Programming Options
Flash the hood pin switch (see on page 1)
—the parking lights will stay on for up to 20 seconds.
Before the lights go out, press and hold the brake pedal and then press one of the following buttons:
LOCK.................................................to access mode 1; or
UNLOCK.................................................to access mode 2
The parking lights will flash and the horn will honk (if programmed) once or twice to confirm entry into a mode.
Release the brake pedal.
After selection the function, press one of the corresponding buttons to select the option.
LOCK
for
Option 1,
UNLOCK
for
Option 2,
TRUNK
for
Option 3.
Programming Options
MODE 1
(‘ indicates defauit setting)
FUNCTION 1 - Ignition-controlled door locks
OPTION 1*
Ignition-controlled door locks disabled
OPTION 2
Ignition-controlled door locks enabled
OPTION 3
Ignition-controlled door locks disabled
FUNCTION 2 - Secure Lock
OPTION 1*
Secure Lock Disabled
OPTION 2
Secure lock enable
OPTION 3
Secure lock disabled 0 C-second disarm pulse )
FUNCTION 3 - Passive / Active Arming of the Starter Kill
OPTION 1*
Starter kill passive (1-minute timeout.)
OPTION 2
Starter Kill active
OPTION 3
Starter Kill passive {3-minute timeout.)
FUNCTION 4 - Lock Pulse Duration
OPTION 1*
7/10-second lock ñ unlock pulses
OPTION 2
4-second lock / unlock pulses
OPTION 3
7/10-second lock pulse and two d-second unlock pulses
FUNCTION 5 - Flashing LED
OPTION 1*
Enabled (Will turn off once the engine is under ignition key control)
OPTION 2
Disabled
OPTION 3
Enabled (Must disarm starter kill in order to stop flashing)
MODE 2
(* indicates defauit setting)
FUNCTION 1 - ENGINE RUN TIME
OPTION 1
4-minute run time in gas mode / 9-minute in diesel mode.
OPTION 2*
15-minute run time in gas mode / 20-minute in diesel mode.
OPTION 3
25-minute run time in gas mode / 30-minute in diesel mode.
FUNCTION 2 -TURBO MODE
OPTION 1
Turbo mode enabled
OPTION 2*
Turbo mode disabled
OPTION 3
Turbo mode enabled
FUNCTION 3 - ENGINE TYPE- Gas or Diesel
OPTION 1
Diesel engine mode (in cold weather mode runtime 20 min).
OPTION 2*
Gasoline engine mode
OPTION 3
Diesel engine mode
FUNCTION 4 - AUX 1 programming
OPTION 1
Priority door access
OPTION 2*
Horn confirmation on 2nd press of
LOCK
button
OPTION 3
Horn confirmation when pressing LOCK button
Installation Guide
Diagnostics - Parking Light Fiash Tabie
Flashes
Description
1
•
Doors locked, starter kill armed.
•
Run time has expired.
•
TRUNK button pressed.
•
Start signal received by the module.
•
Cold weather mode cancelled.
2
•
Remote start attempt cancelled by remote.
•
Doors unlocked, starter kill disarmed.
•
Exiting ignition valet
•
Power-up reset
3
•
Entering cold weather mode.
•
Entering ignition valet.
3 slow flashes^
>after a failed start attempt | The module did not detect a tach signal.
4
♦ +12 V detected on the brake input wire either while cranking or during run time.
•
Entering multi-speed tach programming.
5 Slow
• Start attempt failed because no tach signal has been programmed.
5 Fast
• Tach signal programmed.
6
• A remote start was attempted while a tach-before-crank signal was detected before cranking.
8
• Unit reset see “Resetting the Module” (p.1)
10
• A ground (-) signal was detected on the hood pin input wire.
1 —pause —
1
—
pause
—
5 flashes
[During the
transmitter
programming
procedure]
♦ Transmitter has been programmed.
1 - pause - 2
•
There was a remote start attempt while the vehicle was in valet mode.
•
Failed start: vehicle’s low battery voltage.
ON SOLID for 3
seconds^.
^followed by 1 flash
Exiting cold weather mode
^followed by 3 flashes
Entering cold weather mode
ON continuously
•
Idle mode:
Idle mode is engaged
♦
Run time:
The vehicle has been remote started and is in runtime.
ON continuously
While the brake
pedal is
pressed.
• Confirms that cold weather mode is engaged
ON 2 seconds
• The hood has been opened and a ground (-) signal has been detected on the hood pin input
wire.
ON 4 seconds
• Locking or unlocking a door (with Door pulses configured to 4 sec.)
ON 20 seconds
• The hood pin has been flashed and you are now in the programming centre.
