Avanti WC412D - Manual (Page 11)

^ Shelves
Shelving is chrome plated. To accommodate different size bottles, they
can be moved up or draw by sliding them out the tracks first. Shelves are
designed to accommodate maximum amount of bottles.
^ Wine Rack
There is an additional wine rack at bottom section of the unit where you
can store up to 4 wine bottles. This rack is removable for cleaning purpose.
NOTE:
When you use the wine cooler for the first time or restart the wine cooler
after having been shut off for long time .there could be a few degrees
variance between the temperature you select and the one indicated on
the LED readout.This is normal and it is due to the length of the activation
time .Once the wine cooler is running for a few hours everything will be
back to normal.
Also,there is a 6 to 8’F variance between the top and bottom shelves of the
wine chiiler.Therefore.If you have set the wine chiller for red wine only and
the temperature reads 60 F and you want to place a mix of white and red
wines,you should place the wine bottles on the bottom shelves and the red
wines on the top shelves.
CARE AND MAINTENANCE
CHANGING THE LIGHT BULB
NOTE;
All parts removed must be saved to do the replacement of the light bulb.
Before removing the light bulb, either unplug the refrigerator or disconnect
the electricity leading into the refrigerator at the main power supply. Failure
to do so' could result in electrical shock or personal injury. •
• Remove the screw®
' Remove the light bulb cover® by pulling the bottom end of the light bulb
cover gently.
■ Unscrew the bulb0.
• Replace with a 10 watt-refrigerator buib that is the same shape and size.
Replace the light bulb cover® and tighten screw®.
10
