345C L Hydraulic Excavator
specifications
Working Ranges
Mass Excavation (ME) boom configuration (6550 mm)
Stick Length
A
Maximum Digging Depth
B
Maximum Reach
at Ground Level
C
Maximum Cutting Height
D
Maximum Loading Height
E
Minimum Loading Height
F
Maximum Digging Depth
2.44 m Level Bottom
G
Maximum Vertical Wall
Digging Depth
Bucket Capacity
Bucket radius at Cutting edge
Bucket digging Force (ISO)
Stick digging Force (ISO)
R2.9TB
R3.4TB
mm
2900
3350
mm
-7041
-7491
mm
11 284
11 703
mm
10 826
11 003
mm
7403
7580
mm
3411
2968
mm
-6879
-7344
mm
-4888
-5296
m
3
2.2
2.0
mm
1735
1735
kN
249
239
kN
235
217
Reach (R) boom configuration (6900 mm)
Stick Length
A
Maximum Digging Depth
B
Maximum Reach
at Ground Level
C
Maximum Cutting Height
D
Maximum Loading Height
E
Minimum Loading Height
F
Maximum Digging Depth
2.44 m Level Bottom
G
Maximum Vertical Wall
Digging Depth
Bucket Capacity
Bucket radius at Cutting edge
Bucket digging Force (ISO)
Stick digging Force (ISO)
