Page 2 SKU 91124
Specifications
Save This Manual
You will need the manual for the safety warnings and precautions, assembly instructions,
operating and maintenance procedures, parts list and diagram. Keep your invoice with this
manual. Write the invoice number on the inside of the front cover. Keep the manual and
invoice in a safe and dry place for future reference.
Safety Warnings and Precautions
WARNING: When using tool, basic safety precautions should always be followed to
reduce the risk of personal injury and damage to equipment.
Read all instructions before using this tool!
1. Keep work area clean. Cluttered areas invite injuries.
2. Observe work area conditions. Do not use machines or power tools in damp or wet
locations. Don’t expose to rain. Keep work area well lighted. Do not use electrically
powered tools in the presence of flammable gases or liquids.
3. Keep children away. Children must never be allowed in the work area. Do not let them
handle machines, tools, or extension cords.
4. Store idle equipment. When not in use, tools must be stored in a dry location to inhibit
rust. Always lock up tools and keep out of reach of children.
5. Do not force tool. It will do the job better and more safely at the rate for which it was
intended. Do not use inappropriate attachments in an attempt to exceed the tool capacity.
ITEM DESCRIPTION
Welding Current 90 AMPs
Duty Cycle 10%@90AMPs
Power Consumption 110VAC, 23 amps
Heat Control Switch on Unit This model is not adjustable
Ground Cable 4 AWG, single insulation, 6 foot
Torch Power Cable 8 AWG, single insulation, 6 foot
Power Cord 3-core, double insulated, 14 AWG, U.L. approved
Power Cord Plug UL Approved
Thermal Overload Both settings: 10 min. shutdown, 3 min. back on with Light
Welder Tip 0.030”; Spare: Welder Tip 0.035 inch;
Will also accept 0.023” welder tip
Wire Size 0.030 inch flux core wire when using 0.030” Welder Tip
Wire Spool Size 4 inches diameter
Overall Dimensions 14-1/2 (L) x 8-1/2 (W) x 15-1/2 (H) inches
Weight 34.45 lbs.
Accessories Spare Welder Tip
Welding Face Shield
Wire Brush / Hammer combination
REV 06/04
