W260F8U/W320F8U/W370F8U
PAGE 22
SPECIFICATIONS
Model: W260F8U
Items Specifications
Size (diagonal) 26 inch
Recommended Resolution 1280X768
Dot Pitch 0.4425mm(H) X0.1475mm (V)
Number of Dots 1280XRGBX768
Viewable Area 566.4mm(H) x339.84mm (V)
LCD panel
items
Color Display 16.7million
Color System NTSC
Sound System M
PC, DVI Qualified Input Format VGA/SVGA/XGA/WXGA 60Hz
YPbPr Input Format 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Audio Output Consumption 2x5w
AV Output One way
Headphone Output One way
AV (S-Video) Input Two ways (audio is using in community)
YPbPr Input One way
PC Input One way
DVI Input One way
Voltage Input
Rated Power Consumption
Please refer to the back label
Standby Power Consumption ≤2W
Unit Dimension
804mm（W）×510mm(H)×294mm(D)
（including the pedestal）
804mm (W) X436mm (H) X106mm (D)
(Not Including the pedestal)
Recommended resolution in PC mode 1280x768 60Hz
Unit Weight 17.5kg（Approx.）
