Chromalox 8003 User's Manual 5
P1 = Input Type and Standard Range
Range
0 = TC type L 0 / +800 °C
1 = TC type J 0 / +800 °C
2 = TC type K 0 / +999 °C
3 = TC type N 0 / +999 °C
4 = RTD type Pt 100 -199 / +500 °C
5 = RTD type Pt 100 -19.9 / +99.9 °C
8 = TC type L 0 / +999 °F
9 = TC type J 0 / +999 °F
10 = TC type K 0 / +999 °F
11 = TC type N 0 / +999 °F
12 = RTD type Pt 100 -199 / +999 °F
P2 = Initial Scale Value
Not present when P1 = 5
The initial and full scale values are used by the PID
algorithm to calculate the input span.
P3 = Full Scale Value
Not present when P1 = 5
The initial and full scale values are used by the PID
algorithm to calculate the input span.
Note: the minimum input span (P3 - P2) is 300°C or
600°F for TC input and 100°C or 200°F for RTD input.
P4 = Output Configuration
H = Heating HC = Heating / cooling
P5 = Heating Output Type
rEL = Relay
SSr = SSR
The output type selected here must match hardware
jumper setup (see page 2).
P6 = Cooling Element
Available only when P4 = HC
AIr = Air
OIL = Oil
H2O = Water
P7 = Alarm 1 Type
Available only when P4 = H
0 = None
1 = Process alarm (absolute)
2 = Band alarm (+ and - deviation)
3 = Deviation alarm
P8 = Alarm 1 Operation
Available only when P7 is different from 0
H = High Alarm L = Low Alarm
(outside if band alarm) (inside if band alarm)
