Evenflo Symphony 65 - Manual (Page 14)

Rear-facing
Level Line
buckle storage
Recline Positions Rear-facing use ONLY 1 Forward-facing 10 - 18 kg (22-40 lbs) when using Harness Straps 3 2 Forward-facing 10 - 29.4 kg (22 - 65 lbs) when using Harness Straps AND in Booster Mode 18 - 49.8 kg (40 - 110 lbs) Arrow must be level with ground when child restraint is used rear-facing.
T H IS S ID E U P
buckl e storag e
Recline Positions Rear-facing use ONLY 1 Forward-facing 10 - 18 kg (22-40 lbs) when using Harness Straps 3 2
Forward-facing 10 - 29.4 kg (22 - 65 lbs) when using Harness Straps AND in Booster Mode 18 - 49.8 kg (40 - 110 lbs) Arrow must be level with ground when child restraint is used rear-facing.
Recline Positions Rear-facing use ONLY 1
Forward-facing 10 - 18 kg (22-40 lbs) when using Harness Straps 3
2
Forward-facing 10 - 29.4 kg (22 - 65 lbs) when using Harness Straps AND in Booster Mode 18 - 49.8 kg (40 - 110 lbs) Arrow must be level with ground when child restraint is used rear-facing.
24
4a. Secure the child
restraint –
SureLatch Con-
nector.
Using your full weight,
push the child restraint
firmly into the vehicle
seat, as shown, to lock
in place.
Rear-facing Belt Path
3. Increase recline
angle, if necessary.
If level line is not parallel
to the ground, discon-
nect lower anchor
connectors and place
a tightly rolled towel/
small blanket beneath the
front edge of the child
restraint.
Repeat Step 2.
Tightly rolled towel
or small blanket
Note: In some vehicles, you may
need to prop up the SureLatch
connector while pushing down-
ward on the seat to secure it
tightly. Repeat for the other
SureLatch connector.
IMPORTANT: Infants may have difficulty breathing when
in a sitting position. Make sure they recline enough for their
head to lie back comfortably and safely. Failure to properly
recline the child restraint could increase the child’s risk
of serious injury or death.
Rear-facing Installation with Lower
Anchor Connectors
4. Ensure child restraint is secure.
To secure a child restraint that has SureLatch connec-
tors, go to Step 4a. To secure a child restraint that has
Quick Connectors, go to Step 4b.
25
4b. Secure the child
restraint –
Quick Connector.
Using your full weight,
push the child restraint
firmly into the vehicle
seat while pulling up on
the lower anchor strap
to tighten, as shown.
Recline Positions Rear-facing use ONLY 1 Forward-facing 10 - 18 kg (22-40 lbs) when using Harness Straps 3 2 Forward-facing 10 - 29.4 kg (22 - 65 lbs) when using Harness Straps AND in Booster Mode 18 - 49.8 kg (40 - 110 lbs) Arrow must be level with ground when child restraint is used rear-facing.
Rear-facing Belt Path
IMPORTANT: To properly secure this child restraint, it
MUST NOT move more than 25 mm (1 inch) from side to
side or front to back at the rear-facing belt path. If you
cannot tightly secure the child restraint, try again or move it
to another location.
Rear-facing Installation with Lower
Anchor Connectors
IMPORTANT: To properly secure this child restraint, it
MUST NOT move more than 25 mm (1 inch) from side to
side or front to back at the rear-facing belt path. If you
cannot tightly secure the child restraint, try again or move it
to another location.
