MTD 310-181-000 - Manual (Page 11)

Models 180 and 181
PARTS LIST FOR MODELS 180 AND 181 SNOW THROWERS
REF.
NO.
PART
NO. CODE
DESCRIPTION
REF.
NO.
PART
NO. CODE
DESCRIPTION
1 751-0353 Gas Tank Cap 50 736-0231 FI-Wash. .344" I.D. x 1.25"
2 731-0702 21" Shroud 51 712-0296 Hex Patch L-Nut,3/8-24 Thd.
3 710-0429 Hex B-Tap Scr. #10 x .38" 52 754-0367 N “V”-Belt
4 736-0370 Spr.-Wash. .206" I.D. x .448" 53 784-5176 Belt Cover
5 710-0892 Hex L-Wash. Hd. AB-Tap 54 710-0352 Hex B-Tap Scr. V4" x .38" Lg.
1/4 X .62" Lg. 55 710-0451 Carriage Bolt 5/16-18 x .75"
6 749-0705 Upper Handle 56 748-0234 Shid. Spacer .50" Dia. x .27"
7 726-0135 Cap Speed Nut 57 736-0326 FI-Wash. .510" I.D. x 1.0" O.D.
8 731-0791 Control Handle Ass’y —L.H. 58 756-0550 N 3/8" “V’’-Pulley 1/2-20 L.H. x 6"
9 736-0140 FI-Wash. .385" I.D. x .62" 60 784-5174 Bearing Cup
10 710-0796 Truss Mach. Hi-B Tap Scr. 61 741-0124 Ball Brg. .669" I.D. x 1.574"
#12 X 1.5" Lg. 62 784-5325C 638/N 21" Blower Hsg. Ass’y.
11 736-0142 FI-Wash. .281" I.D. x .5" O.D. 63 710-0323 Truss Mach. Scr. 5/16-18 x
12 731-0815 Control Panel Half .75" Lg.*
13 728-0173 Pop Rivet .188" Dia. 64 732-0357 Extension Spring 1.12" Lg.
14 746-0506 Clutch Cable 35" Lg. 65 731-0851 Chute Flange Keeper
15 731-0816 Control Panel Half 66 749-0810 N Wheel Axle Vz" O.D. x 20.6" Lg.
16 726-0100 Push Cap 3/8" Rod 67 736-0329 L-Wash. 1/4" I.D.*
17 720-0201A N Knob—3/8" Dia. Hole 69 710-0167 Carriage Bolt V4-20 x .50"*
18 715-0138 Roll Pin 1/8" Dia. x .63" Lg. 70 736-0173 FI-Wash. .281" I.D. x .73"
19 784-5344 Chute Crank Ass’y. 71 712-0291 Hex L-Nut 1/4-20 Thd.
20 710-0405 Curved Carriage Bolt 5/16-18 72 731-1033 Shave Plate
X 1.75" Lg. 74 710-0896 Hex Wash. B-Tap Scr. V a x
21 735-0218A N Chute Crank Grommet .62" (Spec.)
22 712-0287 Hex Nut 1/4-20 Thd. 75 784-5485 N Auger Ass’y. 21"
23 784-5178 Upper Chute Crank Brkt. 76 731-0781A N Rubber Spiral—L.H.
, 24 749-0713 Lower Handle 77 731-0782 Rubber Paddle
25 751-0354 Primer 78 736-0400 FI-Wash. .218" I.D. x .62"
26 731-0732 Plastic Plug 79 710-1003 Hex Wash. B-Tap Scr. #10 x
27 725-0954 Plastic Key (Tech. Eng.) .62" Lg.
28 784-5168B 638/N Dash Panel Ass’y. 80 731-0780A N Rubber Spiral—R.H.
30 736-0119 L-Wash. 5/16" I.D.* 81 710-0875 Hex Wash. TT-Tap Cl-Scr.
31 712-0267 Hex Nut 5/16-18 Thd.* 1/4-20 X .75" Lg.
32 723-0354 Primer Hose—11" Lg. 84 714-0507 Cotter Pin 3/32" Dia. x .75"
33 726-0205 Hose Clamp—Vz" Dia. 85 736-0133 FI-Wash. .406" I.D. x 1.25"
34 751-0535 Gas Line—12" Lg. 86 741-0403 Hex Bushing .385" I.D.
35 726-0225 Cable Tie—17.75" Lg. 87 726-0240 Cable Tie
36 784-5341 Engine Support Brkt. 88 726-0649 Hex Tap Scr. 3/8-24 x .88" Lg.
37 784-5495 N Engine Support 89 736-0108 FI-Wash. .510" I.D. x .75"
38 712-0298 Hex Jam Nut V4-20 Thd. 90 734-1176 Wheel & Tire Ass’y. 7" x 1.5"
39 736-0242 Bell-Wash. .345" I.D. x .88" 91 731-0915 Lower Chute
41 710-0442 Hex Bolt 5/16-18 X 1.5" Lg.* 92 710-0255 Truss Mach. Scr. 1 / 4 -20 x .75"
42 756-0416A N 3/8" “V”-Pulley Half .625" 93 751-0435 Fuel Tank—Two Qt.
I.D. X 6.0" O.D. 94 731-0921 Upper Chute
44 784-5180A N Idler Brake Brkt. Ass’y. 95 09966 Knob Handle Ass’y.
45 750-0589 Spacer .325" I.D. x .625" 97 710-0276 Carriage Bolt 5/16-18 x 1"*
O.D. X .875" 98 731-0524 Control Disc Pin
46 756-0313 Fl-ldler w/Flanges 2.12" O.D. 99 736-0162 FI-Wash. .635" I.D. x 1.04"
47 748-0201 Spacer .635" I.D. x .89" O.D. O.D.
X .57" 100 736-0256 FI-Wash. .635" I.D. x 1.0" O.D.
48 712-0158 Hex L-Nut 5/16-18 Thd. 101 736-0176 FI-Wash. .25" I.D. x .93"
49 710-0157 Hex Bolt 5/16-24 x .75" Lg.* — 390-697 3 HP 110V Electric Start
*For faster service obtain standard nuts, bolts and washers localiy.
If these items cannot be obtained locally, order by part number and
size as shown on parts list.
CODE: N notates a new part (not previousiy existing). A three digit
number is the color code (use if color or finish is important when
ordering parts). See chart at right, [i.e., (part no.)-638 for Red Finish], .|
Color Codes
638—MTD Red
483—Charcoal Grey
488—Radiant Yeliow
