Models 685 and 689
PARTS LIST FOR MODELS 685 AND 689 POWER VACUUMS
REF.
NO.
PART
NO.
CODE DESCRIPTION
REF.
NO.
PART
NO.
CODE DESCRIPTION
1 05778B Clutch Grip Ass’y- 43
—
Engine
2 711-0679 Clevis Pin .375" Dia. x 1.88" 751-0581 Muffler Guard Ass’y. (Incl.
3 747-0154 Clutch Rod 32" Lg. Hardware)tt
4 749-0787 Handle Brace 46 748-0201 Spacer .63" I.D. x .88" O.D. x
5 — Part of Engine .56" Lg.
6 710-0892 Hex Wash. Hd. AB-Tap Scr. 47 14530 Side Plate
1/4" X .62" Lg. 48 715-0247 Spring Pin Spiral 3/16" Dia. x
7 14558 Belt Guard 1" Lg.
8 714-0114 Square Key 1/4" x 2" Lg. 49 748-0288 Drive Pinion
9 14557A Air Vane Plate Ass’y- w/Pulley 50 710-0170 Hex Locking Bolt 5/16-24 x
10 710-0442 Hex Bolt 5/16-18 X 1.5" Lg.* .62" Lg,
11 754-0219 “V”-Belt 51 736-0159 FI-Wash. .34" I.D. x .87" O.D.
12 736-0119 L-Wash. 5/16" I.D.* 53 734-1035 Wheel Ass’y. Comp. 12" x 3"
13 712-0267 Hex Nut 5/16-18 Thd.* (Incl. Ball Bearings)
14 16454 Engine Mounting Frame Ass’y. 54 750-0194 Spacer .63" I.D. X 1.0" O.D. x
15 714-0115 Cotter Pin 1/8" Dia. X 1" Lg.* .94" Lg.
16 736-0187 FI-Wash. .63" I.D. xl.25" O.D. 55 710-0118 Hex Bolt 5/16-18 X. 75" Lg.*
17 736-0921 L-Wash. 1/2" I.D.* 57 747-0542 Height Adjustment Crank
18 712-0206 Hex Nut 1/2-13 Thd.* 58 736-0117 FI-Wash. .385" I.D. X .62" O.D.
19 712-0107 Hex Cent. L-Nut 1/4-20 Thd. 59 720-0171 Crank Knob
20 732-0411 Extension Spring .78" O.D. x 61 710-0136 Hex Bolt 1/4-20 X 1.75" Lg.
.75" Lg. 62 764-0162A Vacuum Bag—Felt
21 734-1036 Swivel Caster Wheel 5" Dia. x 63 1539-019 Push Speed Nut .25" Dia. Stud
1.25" 64 749-0785 Lower Handle
22 732-0409 Extension Spring .38" O.D. x 66 726-0100 Push Nut 3/8" Dia.
7.50" Lg. 67 711-0737 Stud Pin .250" Dia. x 1.75"
23 716-0104 Snap “E”-Ring .50" Dia. Shaft 69 714-0145 Internal Cotter Pin 3/8" Dia.
24 756-0367 “V”-Pulley 5/8" X 6.50" O.D. 70 749-0786 Upper Handle
25 748-0142 Flange Bearing .502" I.D. 71 738-0185 Rear Axle
26 14570 Gear Box Mounting Bracket 72 715-0249 Spring Roll Pin 5/32" Dia. x
27 732-0376 Extension Spring .75" O.D. x 1.12
3.28" Lg. 73 750-0142 Spacer .82" I.D. x 1.0" O.D.
28 14565 Clutch Bracket Ass’y.
X .305 Lg.
29 714-0229 #2 Woodruff Key 3/32" Dia. x 74 736-0175 L-Wash. .265" I.D.
.81" Lg. 75 710-0352 Hex Self-Tap Scr. 1/4" x 3/8"
30 748-0227A Hex Flange Bearing Bronze Lg.
.625" I.D. 76 14556 R.H. Pinion Guard
31 738-0516 Pinion Shaft .50" Dia. x 5" 14555 L.H. Pinion Guard (Not Shown)
32 717-0493 Gear Box Ass’y. Comp. 77 712-0298 Hex Jam Nut 1/4-20 Thd.
33 16273 Caster Arm Ass’y, 78 736-0242 Belleville Washer
34 08348 Drive Shaft 79 736-0300 FI-Wash. .35" I.D. x .87" O.D.
35 748-0136 Bevel Gear .50" I.D. x 14 Teeth 80 750-0528 Spacer .38" I.D. X .50" O.D. x
36 748-0108 Flange Bearing .503" I.D. .18" Lg.
37 753-0218 Gear Box (Incl. Ref. 36 & 38) 81 711-0797 Ferrule 3/8-8 x .38" Dia.
38 748-0110 Flange Bearing .630" I.D. 82 712-0354 Hex Nut 3/8-8 Thd.
39 08187 Gear Box Cover 83 736-0169 L-Wash. 3/8" I.D.*
40 748-0135 Bevel Gear .62" I.D. x 28 Teeth
—
737-0223 10 oz. Tube Benalene #372-0
41 715-0246 Spring Pin Spiral 3/16" Dia. x Grease (3 oz. Req’d.)
1.25" Lg.
42 710-0726 Hex Wash. Hd. AB-Tap Scr.
5/16" X .75" Lg.
ttOptional Parts 'For faster service obtain standard nuts, bolts and washers locally.
If these items cannot be obtained locally, order by part number and
size as shown on parts list.
