Generac Portable Products 2,400 PSI High Pressure Washer
PARTS LIST — PUMP
Item
Part #
Qty.
Description
Item
Part #
Qty.
Description
1
B22I8
1
O'RING, Engine Seal
33
185712
0
KIT, CHECK VALVES
2
97962
3
SHCS, M6 - 1 X 25
13
4
SHCS, M6-I.0x35
3
96795
3
SLEEVE, Grommet Spacer
34
3
O-RING. Check Valve
4
21429
6
BUSHING, Rubber Mount
35
6
ASSY. Check Valve
5
97835
1
O'RING, Housing Seal
47
3
O-RING, Check Valve, White
6
21783
1
THERMAL RELIEF, GPW-
36
185531
0
KIT, HEAD BRASS EG
EG
13
4
SHCS, M6-I.0x35
7
93680
3
SEAL, Oil Piston
37
1
HEAD, Pump
8
97831
3
SPACER, Pilot
38
1
PLUG. 1/8-28
9
B2702
1
HOUSING, Piston
48
4
WASHER, M6 Fiat
10
B5003
1
ADAPTER, Engine
39
185713
0
KIT, PISTON & SPRING
1 1
B57I0
1
VALVE, 1/8 npt 1/5 PSI
1
1
O-RING, Engine Seal
12
97841
3
CAP, Outlet Check Valve
2
3
SHCS, M6 - 1 X 25
13
40946
4
SHCS, M6-I.0x35
5
1
O-RING, Housing Seal
14
185710
0
KIT, AXIAL CAM
40
3
RETAINER, Piston Spring
1
1
O-RING, Engine Seal
41
3
PISTON, Dia. 15 X 65
1
3
SHCS, M6 - 1 X 25
42
3
SPRING, Piston Return
5
1
O-RING, Housing Seal
43
185714
0
KIT, O-RING/SEAL 2300
15
1
WASHER, Brg. 36 X 65 X 6Thk
1
1
O-RING, Engine Seal
16
2
ASSY, Brg. Cage 45 x 65
2
3
SHCS, M6 - 1 X 25
17
3
WASHER, Brg. 45 x 65 X 1
5
1
O-RING, Housing Seal
18
1
CAM, Axial 5.6 7/8"SAE
7
3
SEAL, Oil Piston
19
185287
0
KIT, CHEM INJECT
13
4
SHCS, M6-I.0x35
20
1
FITTING, Chem Inject
23
2
O-RING, Venturi & Seat, Black
21
1
BALL, Chem Inject
27
1
O-RING, Unloader Cap
22
1
SPRING, Chem Inject
30
1
O-RING, Venturi, Yellow
23
1
O-RING, Venturi & Seat, Black
34
3
O-RING. Check Valve
24
1
VENTURI, Chem Inject
44
3
SEAL, Double-Lip
30
1
O-RING, Venturi, Yellov^i
45
1
O-RING, High Pressure Transfer
25
187879
0
KIT, UNLOADER
46
3
O-RING, Outlet CV Cap
23
1
O-RING, Venturi & Seat, Black
47
3
O-RING, Check Valve, White
26
1
CAP, Unioader
27
1
O-RING, Unloader Cap
Item numbers 14,
19, 25, 33, 36, 39, and 43 are service kits
28
1
SPRING, Unloader
and include all parts shown within the box. Certain parts
29
1
PISTON ASSY, Unloader
may only be available as components of a kit.
31
1
SEAT, Unloader
