PARTS LIST FOR 36” SNOW THROWER MODEL NOS. 190-768 AND 191-768 (Continued)
illus.
No.
Part
No. Description
IHus.
No.
Part
No. 1 Description 1
61 GM180120 Bolt - (J’shaft to Brg.) 3/8-16 x 3/4 Hex Head 95 3903
j
Washer — Deflector to Elbow 3/8 x 7/8 Concave Tooth
62 GM-120388 Washer — (J’shaft to Brg.) 3/8 Med. Flat (7/16 x 1 x .083) 96 4506 Washer — Deflector to Elbow 3/8 Flat Special
63 GM-120382 Washer — (J’shaft to Brg.) (3/8 Med. Lock) (13/32 X 1-1/2 X 16 Ga.)
64 GM-180120 Bolt — (Flange to J’shaft Brkt.) 3/8—16 x 3/4 Hex Head 97 4119 Nut — Deflector to Elbow 1/4—20 Hex Lock
65 GM-9413534 Nut — (Flange to J’shaft Brkt.) 3/8—16 Hex Lock 98 3095 Clip — Connector Link
66 6490 Assembly — Idler Arm (AW) 99 3095 Link — Connector
67 6488 Assembly — Idler Pulley (4-1/2 O.D. A Sec.) 100 6493 Assembly — MTG. Frame (AW)
68 6495 Shield — ^lley 101 GM-180079 Bolt — (Mtg. Frame to Tractor) 5/16—18x1 Hex Head
69 GM-126509 Bolt — (Pulley & Shields to Arm) 1/2—13 x 2-1/4 Carr. 102 GM-446363 Washer — (Mtg. Frame to Tractor) 5/16 Flat 3/8 x 7/8 x .083
70 GM-9417098 Washer — (Pulley & Shields to Arm 1/2 Flat) (17/32 x 1 x .063) 103 GM-271184 Nut & Lock Washer Ass’y. — Mtg. Frame to Tractor
71 GM-138549 Washer — (Pulley & Shields to Arm) 1/2 Shakeproof Lock 5/16-18 Hex
72 GM-120378 Nut — (Pulley & Shields to Arm) 1/2—13 Lt. Hx. 104 3980 Pin — Clevis ( Frame to Header) Assembly to Header
73 6496 Strap — Clutch Rod Mounting 105 3341 Pin — Hair Cotter (Frame to Header) Assembly to Header
74 5759 Spacer — (Idler Brkt. To J’shaft Bracket) 106 6502 Hook — lift Spring
75 GM-180134 Bolt — (Idler Brkt. Spacer, J’shaft Bracket, Flange) 107 3434 Spring — Lift Balance
3/8—16 X 2-1/2 Hex Head 108 6503 Rod — lift
76 GM-9413534 Nut — (Idler Brkt. Spacer, J’shaft Brkt. Flange) 3/8—16 Hex Lock 110 6504 Extension — lift Lever
77 6553 Assembly — Idler Bracket (AW) 111 6505 Pin — Clevis (Ext. to Tractor — Lift Lever
78 3554 Spacer — Idler Bracket 112 6506 Assembly — Rod Support Bracket (AW)
79 6488 Assembly — Idler Pulley (4-1/2 O.D. A Sec.) (MTD with Hardware on Tractor)
80 GM-180192 Bolt -(Spacer & Pulley to Brkt.) 1/2-13x3-1/2 Hex Head 113 6508 Rod — Crank
81 GM-138549 Washer — (Spacer & Pulley to Brkt.) 1 /2 Shakeproof Lock 114 6521 Guide — Crank Rod
82 6556 Chain — (Shaft to Rear Drive Brkt.) 46 Conn. Endless 115 3694 Pin — Clevis (Guide to Support Bracket)
83 GM-180122 Bolt — (Mtg. Brkt.) to Header Channel) 3/8—16 x 1” Hex Head 116 3090 Pin — Hair Cotter (Guide to Support Bracket)
84 GM-120388 Washer — (Mtg. Brkt. to Header Channel) 3/8 Flat (7/16 x 1 x .083) 117 6509 Assembly — Clutch Rod (SW)
85 GM-271190 Nut & Lock Washer Ass’y. — (Mtg. Brkt. to Header Channel) 118 4743 Ext. Clutch Rod (Assembly to Rod)
3/8-16 Hex 119 3090 Pin — Hair Cotter (Ext. to Rod)
86 6498 Belt — Retainer 120 GM-180077 Bolt — Ext. to Clutch Rod Mtg. Strap 5/16—18 x 3/4 Hex Head
87 3090 Pin — Hair Cotter 121 GM-9413447 Nut — Ext. to Clutch Rod Mtg. Strap 5/16—18 Hex Lock
88 4957 Assembly — Deflector & Elbow (AW) 122 6511 V-Belt — (Main Drive) A-66 68.3 — O.C. (Ass’y. on Header)
89 5074 Fitting — Grease 1/4—28 Str. Self Tap 123 6512 Assembly — Belt Popper (AW) (Engine)
90 GM-180016 Bolt — Cable 1/4—20 x 1/2 Hex Head 124 GM-180130 Bolt — Belt Popper to Tractor Grill 3/8—16 x 1-3/4 Hex Head
91 GM-120386 Washer — Cable 1/4 Flat 5/16 x 3/4 x .065 125 GM-120382 Washer — Belt Popper to Tractor Grill 3/8 Med. Lock
92 3052 Deflector Elbow 126 6515 Washer — Belt Popper to Tractor Grill 3/8 Special Flat
93 6558 Molding — Deflector (See Note) (13/32x2-3/8x3/16)
94 GM-180020 Bolt — Deflector to Elbow 1/4—20 x 3/4 Hex Head
