111-902A
111 -902-026
PARTS LIST FOR 111-902A AN D 111 -902-026
REF.
NO.
PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
REF.
NO.
PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
1
710-0606
Hex Scr. 1/4-20
X
1.50" Lg.*
21
736-0119
L-Wash. 5/16" Scr.*
2
746-0249
Throttle Control Ass’y.
22
712-0123
Hex Nut 5/16-24 Thd.*
Comp.
23
734-0841
Wheel Ass’y. Comp.
3
718-0145
Grip
24
738-0213
Axle Bolt
4
749-0384
Upper Handle
25
736-0105
Bell.-Wash. .400 I.D. x .88"
5
712-0267
Hex Nut 5/16-18 Thd.*
O.D.
6
—
Engine
26
710-0289
Hex Scr. 1/4-20
X
.50" Lg.*
7
731-0344
Plastic Label
27
11679
—462 Chute Deflector Ass’y.
8
710-0158
Hex Scr. 5/16-24 x 1.25" Lg.*
28
732-0253
Torsion Spring
9
746-0174
Conduit and Wire
29
726-0106
Palnut
1
/
4
" Rod
10
12946
Handle Mount Brkt. Ass’y-—
30
11130
—462 Adapter Plate
LH.
31
712-0107
Hex Cent. L-Nut V4-20 Thd.
11
15206
—462 Deck Ass’y. Comp.
32
711-0555
Pivot Pin
12
736-0119
L-Wash. 5/16" Scr.*
33
712-0107
Hex Cent. L-Nut V4-20 Thd.
13
712-0123
Hex Nut 5/16-24 Thd.*
34
08405
Reinforcement Plate
14
714-0365
#6 Hi-Pro Key 5/32 x 5/8"
35
710-0567
Hex Scr. 1/4-28 x .62" Lg.
Dia.
36
12945
Handle Mount Brkt. Ass’y.—
15
10769
Blade Adapter Kit
R.H.
16
742-0125
Blade 22"
37
11197
—462 Rear Protective Shield Ass’y.
17
736-0217
L-Wash. 3/8" Scr. H.D.
Comp.
18
10769
Blade Adapter Kit
38
749-0373
Lower Handle
19
710-0459
Hex Scr. 3/8-24 x 1.50" Lg.
39
726-0178
Cable Ties
H.T.
40
710-0405
Curved Hd. Carriage Bolt
20
710-0117
Hex Scr. 5/16-24 x 1.00" Lg.
5/16-18
X
1.75" Lg.
H.T.
41
712-0107
Hex Cent. L-Nut V4-20 Thd.
‘For faster service obtain standard nuts, boits and washers
localiy. if these items cannot be obtained iocaiiy, order by
part number and size as shown on parts iist.
(462—Red Flake)
When ordering parts, if color or finish is important use the ap
propriate color code shown above, (e.g. Red Flake
Finish—15206 (462).)
The engine is not under warranty by the mower manufacturer. If repairs or service is needed on the
engine, please contact your nearest authorized engine service outlet. Check the “Yellow Pages” of
your telephone book under “Engines—Gasoline.”
Find It Fast
In The
Yellow Pages
NOTE
This instruction manual covers various models
and all specifications shown do not neces
sarily apply to your model. Specifications sub
ject to change without notice or obligation.
