MTD 241-670A - Manual (Page 9)

241-670A/680A PARTS LIST FOR MODELS 241-670A AND 241-680A
REF
NO.
PART COLOR
NO. CODE DESCRIPTION
NEW
PART
REF.
NO.
PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
1 710-0258 Hex Scr. V4-20X .62" Lg.* 49 736-0119 L-Wash. 5/16" Scr.* (680A)
(680A) 50 12211 —488 Gear Box Mtg. Brkt. Ass’y.
2 736-0329 Spring L-Wash. V a " S c r . * (680A)
(680A) 51 736-0119 L-Wash.5/16" Scr.* (680A)
3 712-0116 Hex Ins. L-Nut 3/8-24 Thd. 52 710-0118 Hex Scr. 5/16-18 X. 75" Lg.*
(680A) (680A)
4 736-0117 FI-Wash. (680A) 53 736-0329 L-Wash. V a " Scr.* (680A)
5 714-0127 Cotter Pin 1/16" Dia. X. 75" 54 12222 —488 Gear Box Brace (680A)
(680A) 55 712-0267 Hex Nut 5/16-18 Thd.*
6 754-0176 “V”-Beit V4" X 22.76" Lg. (680A)
(680A) 56 736-0119 L-Wash. 5/16" Scr. (680A)
7 710-0938 Set Scr. V4-28X.25" Lg. 57 710-0258 Hex Scr. 1 / 4 -20 X. 62" Lg.*
(680A) (680A)
8 711-0614 P.T.O. Sheave (680A) 58 710-0148 Hex Wash. Hd. F-Tapp Scr. #8
9 756-0194 Idler Pulley (680A) -32X.38" Lg.(680A)
10 12206 Idler Brkt. Ass’y. (680A) 59 717-0325 Gear Box Ass’y.—Comp.
11 732-0157 Spring .38"O.D.(680A) (680A)
12 712-0429 Hex Ins. L-Nut 5/16-18 Thd. 60 714-0126 #9 Hi-Pro-Key 3/16" X 3 / 4 " Dia.
(680A) (680A)
13 738-0140 Shoulder Bolt .437" Dia. x 61 713-0118 Chain #41 X 61 Links (680A)
.180 (680A) 62 713-0723 #41 Master Link V 2 " Pitch
14 711-0596 Control Rod (680A) Type II (680A)
15 12231 . Shifting Finger (680A) 63 710-0118 Hex Scr. 5/16-18 X. 75" Lg.*
16 712-0429 Hex Ins. L-Nut 5/16-18 Thd. 64 736-0119 L-Wash. 5/16" Scr.*
(680A) 65 712-0267 Hex Nut5/16-18Thd.*
17 12213 —488 Pivot Brkt. Ass’y. (680A) 66 736-0119 L-Wash. 5/16" Scr.*
18 732-0273 Compression Spring (680A) 67 12224 Index Plate Ass’y.
19 714-0474 CotterPin1/8"Dia.x.75" 68 12200 —488 Engine Mtg. Frame Ass’y.
Lg.* (680A) 69 748-0227 Hex Flange Bearing .630" I.D.
20 736-0300 FI-Wash. (680A) 70 736-0116 FI-Wash.
\ 21 714-0137 Ht-Pro-Key3/16" X
3
/
4
" Dia. 71 710-0258 Hex Scr. V4-20X .62" Lg.*
X 1.062" Lg. (680A1 72 736-0211 FI-Wash.
22 05054 Shifting Yoke (680A) 73 734-0576 Rear Wheel Ass’y.—Comp.
23 ' 711-0594 Shifting Fork Rod (680A) 75 710-0118 Hex Scr. 5/16-18 X .75" Lg.*
24 720-0132 Grip 76 736-0119 L-Wash. 5/16" Scr.*
25 12208 Index Handle Ass’y. 77 712-0287 Hex Nut V4-20Thd.* (680A)
26 732-0231 Torsion Spring 78 736-0329 L-Wash. 1 / 4 "Scr.* (680A)
27 712-0107 Hex Center L-Nut V4-20Thd. 79 710-0258 Hex Scr.
1
/
4-20
x .62" Lg.*
28 12240 —488 Pivot Brkt. Ass’y.—R.H. (680A)
29 748-0161 Clutch Collar (680A) 80 12232 Chain Guard (680A)
30 748-0164 Sprocket 10 Teeth (680A) 81 712-0107 Hex Center L-Nut V4-20Thd.
31 736-0116 FI-Wash. (680A) 82 726-0188 Cable Tie (680A)
32 716-0115 Snap Ring for .625" Dia. 83 738-0185 Rear Axle (670A)
(680A) 717-0353 Differential Ass’y.—Comp.
33 756-0195 Drive Pulley (680A) (680A)
34 736-0160 FI-Wash. (680A) 84 12233 Lower Handle
35 748-0742 Flange Bearing (680A) 85 712-0107 Hex Center L-Nut V4-20Thd.
36 710-0136 Hex Scr. V
4
-
2
OX 1.75" Lg.* 86 714-0229 #2 Woodruff Key 3/32 x
1/2
"
37 12241 —488 Pivot Brkt. Ass’y.—L.H. Dia. Hdn. (680A)
38 714-0115 Cotter Pin 1/8" Dia. X 1.00" 87 748-0136 Pinion Gear .50" I.D. x 14
Lg.* Teeth (680A)
39 736-0116 FI-Wash. 88 711-0593 Drive Shaft (680A)
40 12217 —488 Front Axle Ass’y. 89 715-0246 Spring Pin Spiral 3/16" Dia. x
41 734-0974 Front Wheel Ass’y.—Comp. 1.25 (680A)
42 748-0176 Flange Bearing .630" I.D. 90 748-0135 Bevel Gear .62" I.D. 28 Teeth
43 736-0116 FI-Wash. (680A)
44 714-0115 Cotter Pin 1/8" Dia. X 1.00" 91 08187 Gear Box Cover (680A)
Lg.* 92 748-0110 Flange Bearing .630" I.D.
45 712-0107 Hex Center L-Nut V4-20Thd. (680A)
(680A) 93 08189 Gear Box (680A)
46 736-0329 L-Wash. V4" Scr.* (680A) 94 748-0108 Flange Bearing .503" I.D.
47 12227 —488 Bearing Support Bkrt. (680A) (680A)
48 710-0118 Hex Scr. 5/16-18 X. 75" Lg. . 95 710-0442 Hex Scr. 5/16-18x1.50 Lg.*
(680A) 1
