Models 692, 693 and 240695
PARTS LIST FOR LEAF B LOWER MODELS 692, 693, and 240695
REF.
NO.
PART NO
Code
DESCRIPTION
REF.
NO.
PART NO.
Code
DESCRIPTION
1
749-0784
Upper Handle (Painted
734-1184
Wheel Ass'y. Comp. 10.5" x
749-0479
Upper Handle (Chrome)
4" (Steel)
2
726-0100
Push Nut 3/8" Rod
734-1185
Tire Only (For 734-1184
3
720-0171
Crank Knob
Wheel)
4
736-0117
Fl.-Wash. .385" I.D. x 62"
734-1183
Rim Only (For 734-1184
O.D.
Wheel)
5
714-0114
Sq. Key 1/4" x 2.0"
L j *
741-0313
Flange Bearings (For 734-1184
6
710-0442
Hex Bolt 5/16-18
X
1.5D" Lg.*
Wheel)
7
16453
Engine Mounting Frams Ass'y
20
736-0159
Fl.-Wash. 34” I.D. x .87" O.D.
8
736-0119
L.-Wash. 5/16” I.D.*
21
710-0170
Hex Locking Bolt 5/16-24 x
9
712-0267
Hex Nut 5/16-18 Thd.*
.64" Lg.
10
736-0187
Fl.-Wash. .63" I.D. x 125"
22
736-0162
Fl.-Wash. (692 Only)
O.D.
23
736-0300
Fl.-Wash. .38" I.D. x .57"
11
714-0115
Cotter Pin 1/8" Dia. x 1.0"
O.D.
I-9-
24
750-0528
Spacer .382" I.D. x .50"
12
712-0206
Hex Nut 1/2-13 Thd.*
X
.180" Lg.
13
736-0921
L.-Wash. 1/2" I.D.*
25
736-0169
L.-Wash. 3/8" I.D.*
14
734-1036
Swivel Caster Wheel E " Dia.
26
712-0354
Hex Nut 3/8-8 Thd.
x 1.25"
27
710-0118
Hex Bolt 5/16-18
X
.75" Lg.*
15
16273
Caster Arm Ass'y.
28
711-0797
Ferrule
16
710-0726
Hex Wash. Hd. "AB" Tap Scr.
29
09966
Hand Knob
5/16"
X
.75" Lg.
30
710-0487
Carriage Bolt 5/16-18 x 2.0"
17
14529
Caster Arm Bracket
Lg-
18
747-0542
Height Adjustment Crenk
31
749-0785
Lower Handle (Painted)
19
734-1035
Wheel Ass'y. Comp. 13" x 3"
749-0481
Lower Handle (Chrome)
(Plastic) (Incl. Bearings)
