INSTRUCTIONS

(Refer to figures 1, 2 and 3)

1. Place the upper handle in position and fasten

with four (4) hex screws and hex centerlock

nuts provided.

2. Place the air duct liner in the elbow of the air

duct and fasten in position as you assemble

the air duct in step 3. (See figure 1.)

3. Place the air duct in position on the blower

housing and fasten with four (4) flat washers

and hex nuts provided.

4. Slide the vacuum bag over the back of the

upper handle and snap the four flaps to hold
the bag.

5. Fasten the deflector on the top of the air duct

with three hex screws, flat washers and hex

nuts. (See figure 1.)

6. Slide the bag over the air duct.

7. Fasten the nozzle to the front of the vacuum

with four flat washers and thumb nuts

provided.

8. Use the following steps on the self propelled

unit only.

9. Fasten the throttle control to the right hand

side of the upper handle with one hex screw
and hex center locknut provided.

10.

Secure throttle control cable to the lower

handle with the cable clip provided.

ASSEMBLY

OPERATION

NOTE

Cable clip must be assembled to

lower handle with the open end
towards the engine. This will pre­

vent wear to the bag.

11. Place ferrule through control lever.

12.

Place flat washer over ferrule and thread

control rod into ferrule about eight or nine
turns.

13. Hook formed end of control rod in the shifting

finger.

14.

Place curved face of spacer towards the

outside of upper handle leh hand side.

15.

Fasten control lever in position with hex

screw and two hex nuts provided.

16. Engage and disengage control lever, check for

free pivoting action. It may be necessary to

readjust the control rod.

1. Service engine with gas and oil. See engine

manual packed with vacuum for complete
instructions for care and maintenance of

engine. READ DIRECTIONS CAREFULLY.

START ENGINE

After the engine has been properly fueled and
oiled (refer to engine operating and maintenance

instructions),

start

engine

in

the

following

manner.

PUSH MODEL

1.

Move throttle control lever on engine to

START position.

2. Crank engine. Pull recoil with a quick firm

pull. Do not pull out so far that rope stops
with a jerk as this will cause rope failure. Do
not allow rope and handle to snap back into
place.

3. After two or three full firm pulls on recoil (or

as soon as engine fires), move speed control

to run position.

4. Operate a new engine at intermediate speeds

and light load for the first few hours as you
would a new automotive engine.

5. To stop engine, move speed control lever on

engine to STOP position.

6. If carburetor needs adjustment to start or for

operation,

see

“Carburetor

Readjustment”

section.

SELF PROPELLED MODEL

1. Place drive engagement lever in the neutral

position (towards the operator).

2.

Move throttle control lever on handle to

START position.

3. Crank engine. Pull recoil with a quick firm

pull. Do not pull out so far that rope stops
with a jerk as this will cause rope failure. Do
not allow rope and handle to snap back into
place.
