MTD 244-689-000 - Manual (Page 3)

Models 675, 685 and 689
PARTS LIST FOR MODELS 675, 685 AND 689 POWER VACUUMS
REF.
NO.
PART
NO.
CODE DESCRIPTION
REF.
NO.
PART
NO.
CODE DESCRIPTION
1 05778B Clutch Grip Ass’y-t 43
—
Engine
2 711-0679 Clevis Pin .375" Dia. x 1.88"t 751-0581 Muffler Guard Ass’y. (Incl.
3 747-0154 Clutch Rod 32" Lg.f Hardware)!!
4 749-0787 Handle Brace (Painted) 46 748-0201 Spacer .63" I.D. x .88" O.D. x
5
--- ■
Part of Engine .56" Lg.t
6 710-0892 Hex Wash. Hd. AB-Tap Scr. 47 14530 Side Plate
1/4" X .62" Lg.t 48 715-0247 Spring Pin Spiral 3/16" Dia. x
7 14558 Belt Guardi 1" Lg.t
8 714-0114 Square Key 1/4" x 2" Lg. 49 748-0288 Drive Pinion!
9 14536A Air Vane Plate Ass’y. 50 710-0170 Hex Locking Bolt 5/16-24 x
(675 and 677)1 .62" Lg.
14557A Air Vane Plate Ass’y. w/Pulley 51 736-0159 Fl-Wash. .34" I.D. x .87" O.D.
10 710-0442 Hex Bolt 5/16-18 X 1.5" Lg.* 53 734-1035 Wheel Ass’y. Comp. 12" x 3"
11 754-0219 “V”-Belt| (Incl. Ball Bearings)
12 736-0119 L-Wash. 5/16" I.D.* 734-1184 Wheel Ass’y. Comp. 10.5" x 4"
13 712-0267 Hex Nut 5/16-18 Thd.* (677 Only)
14 16454 Engine Mounting Frame Ass’y. 741-0313 Bearings (677 Only)
15 714-0115 Cotter Pin 1/8" Dia. x 1" Lg.* 54 750-0194 Spacer .63" I.D. X 1.0" O.D. X
16 736-0187 Fl-Wash. .63" I.D. x1.25"O.D. .94" Lg. (675, 685, 687)
17 736-0921 L-Wash. 1/2" I.D.* 748-0192 Spacer .63" I.D. x .878" O.D.
18 712-0206 Hex Nut 1/2-13 Thd.* X .79" Lg. (677)
19 712-0107 Hex Cent. L-Nut 1/4-20 Thd. 55 710-0118 Hex Bolt 5/16-18 X. 75" Lg.*
20 732-0411 Extension Spring .78" O.D. x 57 747-0542 Height Adjustment Crank
.75" Lg.t 58 736-0117 Fl-Wash. .385" I.D. x .62" O.D.
21 734-1036 Swivel Caster Wheel 5" Dia. x 59 720-0171 Crank Knob
1.25" 61 710-0136 Hex Bolt 1/4-20x 1.75" Lg.
22 732-0409 Extension Spring .38" O.D. x 62 764-0162A Vacuum Bag—Felt
7.50" Lg.t 63 1539-019 Push Speed Nut .25" Dia. Stud
23 716-0104 Snap “E”-Ring .50" Dia. Shaft! 64 749-0785 Lower Handle
24 756-0367 “V”-Pulley 5/8" X 6.50" O.D.t 66 726-0100 Push Nut 3/8" Dia.
25 748-0142 Flange Bearing .502" I.D.t 67 711-0737 Stud Pin .250" Dia. X 1.75"
26 14570 Gear Box Mounting Brackett 69 714-0145 Internal Cotter Pin 3/8" Dia.
27 732-0376 Extension Spring .75" O.D. x 70 749-0786 Upper Handle
3.28" Lg.t 71 738-0185 Rear Axle
28 14565 Clutch Bracket Ass’y.t 72 715-0249 Spring Roll Pin 5/32" Dia. x
29 714-0229 #2 Woodruff Key 3/32" Dia. x 1.12t
.81" Lg.t 73 750-0142 Spacer .82" I.D. x 1.0" O.D.
30 748-0227A Hex Flange Bearing Bronze x .305 Lg.t
.625" I.D.t 74 736-0175 L-Wash. .265" I.D.t
31 738-0516 Pinion Shaft .50" Dia. x 5"t 75 710-0352 Hex Self-Tap Scr. 1/4" x 3/8"
32 717-0493 Gear Box Ass’y. Comp.t Lg.t
33 16273 Caster Arm Ass’y. 76 14556 R.H. Pinion Guard!
34 08348 Drive Shaft! 14555 L.H. Pinion Guard (Not Shown)
35 748-0136 Bevel Gear .50" I.D. x 14 Teeth 77 712-0298 Hex Jam Nut 1/4-20 Thd.t
36 748-0108 Flange Bearing .503” I.D.t 78 736-0242 Belleville Washer
37 753-0218 Gear Box (Incl. Ref. 36 & 38)! 79 736-0300 Fl-Wash. .35" I.D. x .87" O.D.
38 748-0110 Flange Bearing .630" I.D.t 80 750-0528 Spacer .38" I.D. x .50" O.D. x
39 08187 Gear Box Covert .18" Lg.
40 748-0135 Bevel Gear .62" I.D. x 28 Teeth! 81 711-0797 Ferrule 3/8-8 x .38” Dia.
41 715-0246 Spring Pin Spiral 3/16" Dia. x 82 712-0354 Hex Nut 3/8-8 Thd.
1.25" Lg.t 83 736-0169 L-Wash. 3/8" I.D.*
42 710-0726 Hex Wash. Hd. AB-Tap Scr.
—
737-0223 10 oz. Tube Benalene #372-0
5/16" X .75" Lg. Grease (3 oz. Req’d.)
t Parts for Self-Propelled Units (Models 685, 689
and 687) Only,
tt Optional Parts
*For faster service obtain standard nuts, bolts and washers locally.
If these items cannot be obtained locally, order by part number and
size as shown on parts list.
7C — Page 3
