OWNER'S MANUAL
MODEL NO. HDR500F
5 HP 17 Inch
Tiller
Assembiy
• Operation
® Customer Responsibilities
• Service and Adjustments
• Storage
• Troubleshooting
• Repair Parts
For Parts and Service, contact our authorized distributor: call 1-800-849-1297
For Technical Assistance; cai! 1 -800-829-5886
Poulan
163661 11.20.97TR
PRINTED IN U.S.A.
