MODELS 12060, 12077 TROY-BILT® TUFFY® TILLER
ENGINE, ENGINE BRACKETS, AND FORWARD DRIVE MECHANISM
REF
No. PART
No. DESCRIPTION QTY.
REF
No. PART
No. DESCRIPTION QTY
1 1901261* Engine- For Tiiler Modeis 12060 and 17 9758 Bolt-Hex Hd., 5/16-18x1-1/2".......... . 5
12077 only. Tecumseh, recoii start, elec- 18 55080 Belt Pulley Guard............................. 1
tronic solid state ignition, 3 Florsepower. 19 55039 Belt Guide........................................ . 1
Your engine is stamped with a Tecumseh 20 9558 Bolt-Hex Hd., 3/8-16x1-1/2"............ 1
Model Number for identification. Call 21 9090 idler Pulley....................................... , 1
Customer Service before placing your 22 55078 Idler Lever........................................ 1
order................................................... 1 23 9807 Locknut-3/8-16"............................... 1
2 55079 Bracket, Belt Cover............................. 1 24 9902 Washer, Flat..................................... .. 2
3 9912 Lockwasher-5/16".............................. 8 25 9386 Klip Ring........................................... .. 1
4 9563 Bolt-Hex Hd., 5/16-24x1/2"............... 2 26 55037 V-Belt................................................ .. 1
5 55053 Decai-Warning, Hot Surfaces............. 1 27 55034 Spring, Return.................................. 1
6 55086 Belt Cover-(includes decal 55053) 1 28 55033 Bushing-Idler Lever.......................... .. 1
7 9552 Bolt-Flanged Hd., Self-Tapping, 29 9655 Bolt-Hex Hd., 5/16-24x3/4",
1/4-20x1/2“.................................... 7 Grade 5......................................... .. 2
8 9801 Nut-Hex Hd., 5/16-18"....................... 4 30 9944 Washer, Belleville, Transmission
9 50027 Support Washer................................. 1 Pulley........................................... .. 1
10 55077-2 Bracket, Engine, Right........................ 1 31 55031 Pulley-Transmission......................... 1
11 1138-2 Shim...........................................As Req’d 32 55084 Bracket-Cable Mount....................... .. 1
12 55036 Spacer................................................. 1 33 1900766 Decal-Stabilization........................... 1
12A 9301 Key-3/16”x1"...................................... 2 34 90038 Bolt-5/16-18x5/8", Engine Bracket to
13 55035 Pulley, Engine Driven......................... 1 Transmission................................ .. 4
14 9925 Washer, Belleville............................... 1 35 9856 Clevis Pin-Control Cable................... .. 1
15 9549 Bolt-Hex Hd., 3/8-24x1"..................... 1 36 9904 Washer-flat, 3/8"............................. .. 1
16 55077-1 Bracket, Engine, Left.......................... 1
'Contact us if you need assistance before ordering a repiacement engine or engine parts.
