Section

3 Features and Controls

A WARNING

Before

operating

your

machine,

carefully read and understand all
safety, controls and operating instruc­
tions in this Manual, the separate
Engine Owner’s Manual, and on the
decals on the machine.

Failure to follow these instructions can
result in serious personal injury.

Introduction

This section describes the location and

function of the controls on your tiller.

Refer to the following section
“Operation” for detailed operating

instructions.

Practice using these controls, with the

engine shut off, until you understand the
operation of the controls and feel

confident with each of them.

IMPORTANT:

Refer to the separate

engine manufacturer’s Engine Owner’s
Manual for information about the

controls on the engine.

Wheel Drive Pins

A WARNING

Never allow either of the wheels to be
in the FREEWHEEL position when the
engine is running. Always put both

wheels in the WHEEL DRIVE position

before starting the engine.

Failure to comply could cause loss of

tiller control, property damage, or

personal injury.

Each wheel is equipped with a Wheel
Drive Pin (A, Figures 3-2 and 3-3) that

secures the wheel to the wheel shaft (B).

The wheels can be positioned in either a
WHEEL DRIVE or a FREEWHEEL mode.

Forward

Clutch Bail

Depth Regulator

Reverse Clutch

Control (Models

12209/12210)

Handlebar Height

Adjustment

Wheel Drive Pin

(on each wheel)

Figure 3-1: Features and controls (5.5HP Model shown)

Before starting the engine, put both

wheels in the WHEEL DRIVE position by

inserting the Wheel Drive Pins through

the wheel hubs and the wheel shaft. This

“locks” the wheels to the wheel shaft,
causing the wheels to turn when either

the Forward Clutch Bail or the Reverse

Clutch Control (Models 12209/12210) is

engaged.

Use the FREEWHEEL mode only when the

engine is not running. In FREEWHEEL,

the Wheel Drive Pins are placed only
through the holes in the wheel shaft (not

the wheel hubs), thus allowing the wheels

to turn freely when the tiller is pushed or

pulled by hand.

To Place the Wheels in WHEEL DRIVE or

FREEWHEEL:

A

WARNING

Do not place the tiller on its side when
changing the wheel drive positions as
doing so could result in gasoline
leaking from the fuel tank.

Failure to follow this instruction could
result in personal injury or property
damage.

1. Stop the engine, disconnect the spark

plug wire from the spark plug and allow

the engine to cool.

2.

Raise one wheel off the ground and

place a sturdy support under the

transmission.

3.

Remove the hairpin cotter (C, Figures

3-2 and 3-3) from the wheel drive pin (A).

10
