Troy-Bilt 3114GR - Manual (Page 9)

MODELS 3312GR, 3312GRS & 3212GR
REF.
NO.
PART
NO.
QTY.
DESCRIPTION REQ.
REF.
NO.
PART
NO.
QTY.
DESCRIPTION REQ.
1 B1744390 Fuel Tank Pad ........................... 1 22 B1747738 J-Clip......................................... 3
2 B1756044 Fuel Tank Gauge........................ 1 23 B1186309 FI. Screw 1/4-20 x 5/8 .............. 3
3 B1756460 Fuel Tank (Incl. Ref. 2).............. 1 25 B1752909STB Heat Shield................................ 1
4 B1752795 Fuel Line................................... 1 26 B1752912 Elbow, 90°................................ 1
5 B1750687 Hose Clamp............................... 2 27 B1185140 Lock Washer, Special ................ 2
6 • Washer, Lock 1/4....................... 1 28 B1752911 STB Heat Shield ............................... 1
7 • Hex Screw 1/4-20 x 1................. 1 29 B1752890 Muffler...................................... 1
8 B1737118 Knob ........................................ 2 30 B1185986 Speed Nut #10-24..................... 9
9 B1755926 Throttle Control......................... 1 31 B175291OSTB Heat Shield................................ 1
10 B1755927 Choke Control............................ 1 32 B1747993 Socket Hd. Screw 5/16-18 x 3/4 2
11 • Phil. Hd. Screw #10-24 x 5/8 . 9 33 • Screw, Hex Hd. 5/16-18 x 2 . . 1
12 • Keps Nut #10-24....................... 4 34 • Screw, Hex Hd. 5/16-18 x 1-1/2 3
13 B1748014 Grommet................................... 1 35 B1187474 Sq. Key 1/4 x 1-1/2.................... 1
14 B1727491 Fuel Filter.................................. 1 36 B1747148 Sheave...................................... 1
15 B1186330 FI. Screw 5/16-18 x 7/8............. 1 37 B1755341 Electric Clutch............................ 1
16 B1750962 Screw #10-24 x 5/8................... 4 38 B1744455 Special Washer.......................... 1
17 • Hex Nut 5/16-18........................ 4 39 • Lock Washer 7/16...................... 1
18 • Lock Washer 5/16 ..................... 4 40 B1744454 Hex Hd. Screw 7/16-20 x 3
19 * Engine, B&S 12 H.R Model (Grade 5).................................. 1
281707 ..................................... 1 41 • Lock Washer 5/16 (L.H. Rear) 1
20 B1735531 Wire Tie.................................... 3 42 • Flat Washer 5/16....................... 2
21 B1752883GAR Heat Shield (Model 3212GR). 1 43 B1754787 Clutch Retainer.......................... 1
B1752883STB Heat Shield (Model 3312GR). 1 44 B1755340 Spacer ...................................... 1
Common Hardware — Purchase Locally (Specify Grade 5 for screws and bolts)
Engine warranty service and repair parts are available from your
local authorized Briggs & Stratton engine dealer.
