MODELS 644H & 645A
REF
NO.
PART NO.
DESCRIPTION
1
GW-9517
Snap Ring
2
GW-1714
Bearing, Tapered Roller (with race)
3
GW-50043
Support Washer, Rear
4
711-04110
Drive Shaft (CRT)
5
GW-1224-1*
Shim, Rear Bearing Cap, .010“ thick
GW-1224-2*
Shim, same as above, except .030“ thick
GW-1224-3*
Shim, same as above, except .005“ thick
GW-1224-4*
Shim, same as above, except .062“ thick
—
GW-1325C
Shim Set (Inch the following shims:
two #1224-1, two 1224-2 & one #1224-4)
Use as required to obtain between .005” and .015” allowable end-play.
