Supplemental List of Parts 1 200 Machine
Note: The telerence and part numbers shown below are to be used in place
of [larts enumerated on List of Parts for 2000 Machine
REF NO.
PART NO.
1
382127
38
382845-451
39
383491-451
COVERS AND ADD-ONS (Supplement to page 3)
DESCRIPTION
Arm Top Cover (Cream Tint)
NEEDLE BAR DRIVE AND HAND WHEEL (Supplement to page 5)
REF NO PART NO.___________________ DESCRIPTION____________________
25
383506-451 Hand Wheel with Name Plate
TENSION MODULE (Supplement to page 13)
DESCRIPTION
REF NO____PART NO._____________________ ______________________________
1
382082-452 Thread Take-up Spring with Thread Guard
382081-451 (Brown)
4
382081-452 Thread Guard (Brown)
38
382083-452 Tension Module Complete (all parts 1 37 in
cluded)
Form 730- OA Supplement
Printer I S A
