PART НО. DESCRIPTION PART N0. DESCRIPTION
2 410380 Feed Crank Pin Center (small)
3 376795 Feed Crank Pin Center (large) 41 410370 Feed Regulator Stud Bushing
4 544204-001 Feed Crank Pin Center Screw(2) 42 544204-001 Feed Regulator Stud Bushing Set Screw
5 410381 Feed Crank Pin 43 410409 Feed Regulator Stud Collar Comp.
6 543801-006 Feed Crank Pin Retaining Ring 44 504007 Feed Regulator Stud Collar Screw
7 410382 Feed Crank Eccentric Pin Comp. 45 543801-007 Feed Crank Eccentric Pin Retaining Ring
47 412694 Throat Plate Position Screw
10 410387 Feed Lifting Cam Slide Block
11 543818-010 Feed Lifting Cam Slide Block Retaining Ring
12 410385 Feed Lifting Cam Comp.
13 544204-001 Feed Lifting Cam Set Screw(2)
14 410384 Feed Lifting Cam Comp.
15 412730 Throat Plate
16 504050-851 Throat Plate Screw
19 376852 Feed Regulator Crank Rod Comp.
20 544204-001 Feed Crank Eccentric Pin Screw
21 410363 Feed Crank Rod Pin
24 543801-006 Feed Crank Rod Pin Retaining Ring
25 410360 Feed Cam Comp.
26 544203-001 Feed Cam Screw(2)
27 410362 Feed Crank Rod
28 543802-014 Feed Cam Retaining Ring
30 376850 Feed Regulator Crank Rod Comp.
31 410376 Feed Regulator Dial Spring Bracket
32 410377 Feed Regulator Dial Sphing
33 544212-001 Feed Regulator Dial Spring Screw
34 410375 Feed Regulator Dial Spring Bracket Comp.
35 544213-001 Feed Regulator Dial Spring Bracket Screw
38 412788-003 Feed Regulator Dial Comp.
