THREADING THE BOBBIN CASE
Pull thread at least 3 inches from bobbin.
Insert bobbin in bobbin case so that
thread will unravel clockwise .
Fig. 1
^siot pyll thread into slot of bobbin case
as shown in Fig. 2.
■ Thread
Fig 2
Draw thread under the tension spring and
into the fork-shaped opening of the spring
as shown in Fig. 3.
Tension Spring
Fig. 3
Pull thread through hole in bobbin case
finger as shown in Fig. 4.
(Recommended for zigzag sewing only)
Fig. 4
Loose
TO ADJUST BOBBIN TENSION
• Turn screw on side of bobbin
case clockwise to increase
tension.
Turn screw on side of bobbin
case counterclockwise to
decrease tension.
Fig. 5
CORRECT
INCORRECT
TOP TENSION TIGHT
BOTTOM TENSION LOOSE
INCORRECT
TOP TENSION LOOSE
BOTTOM TENSION TIGHT
\
