18
19
MACHINE No. 114-29
For Sewing Two or Four Hole Buttons, 50 ligne.
Makes cross stitches in four hole buttons and can be adjusted
for two hole and bar buttons. Makes 21 stitches, including the
fastening stitch. Thread cutter. Clamp vibrates Across the cylinder.
Speed 1500 R. P. M.
NOTE: THIS MACHINE IS THE SAME AS THE NO. 114-28
MACHINE, WITH THE FOLLOWING EXCEPTIONS:
Name
Feed Cam with two each 190J,1192C,17874,
124616,124630 and ten 335J,ln place of
124690.................................................................
Thread Nipper (lower) Lever Guide, In
place of 124622...................................................
No. Plate
124688 23170
124630 23170
ATTACHMENTS AND ACCESSORIES
No. Plate Name
59797 23174 Button Tray with two wood screws 1 1/4
in, N0.14..............................................................
124958 23157 Cylinder Base Plate with two 453C...........................
18420 23157 “ * " Hinge Connection,...
18423 23157 * ■ ■ ■ • Hinge
Pin.......................................................................
453C 23157 Cylinder Base Plate Hinge Connection
Hinge Pin Set Screw...........................................
134E 23157 Cylinder Base Plate Screw..........................................
124959 23157 Cylinder Base Plate (hinged) complete.
Nos. 124958, two each 18420, 18423,
three wood screws 1 1/4 In, No. 12
and four 134E.....................................................
124975 Cylinder Base Plate 124959 with 124966..
124960 23157 Machine Supporting Bracket (lower)........................
178J 23157 • • ■ n Screw
124961 23157 • ■ " (upper)..........................................................
1396J 23157 " ■ • « Screw
124962 23157 " “ Link (lower)....................................................
124963 23157 • ■ • (upper)..........................................................
124964 23157 • * " Hinge Rivet...................................................
124965 23157 “ ■ * Lock Plate....................................................
190333 23157 » * ... Locij
Stud......................................................................
124964 23157 Machine Supporting Link Lock Plate Rivet
124966 23157 Machine Support complete. Nos. 178J,
1396J,124960 to 124963,T24965,190333
and four 124964..................................................
120346 23157 Oiler (copper plated) with 120347.............................
120347 23157 " Spout, 8 1/2 In. long............................................
11831 23157 Screw Driver (large)....................................................
26026 23157 * " (small)................................................................
4822 23157 Wrench for 1547..........................................................
10875 23157 * * 1518,1520,1649,1650 and 1662.
17905 23157 ' • 1176,1178,1654,1655 and 1676.
25200 23157 " « 1527.................................................................
27662 23157 • ■ 1254 and 1508.................................................
