FOOT LIFTER PARTS
No.
Plate
Name
6439
--------- Chain, 36 In. to 45 In. with 56864 and
56865.......................................................................................
Note:
When ordering No. 6439, state length required.
4879
20633 Chain Connecting Link....................................................................................
56864
20656
'' Hook (large).............................................................................
56865
20656
"
" (small)........................................................................
126249
20633 Treadle..............................................................................................................
4882
20633
”
Shaft...............................................................................
126250
20633
"
Spring.............................................................................
150451
20633
"
Stand..............................................................................
150452
20633
Treadle
complete. Nos. 4879,4882,126249,
126250,150451
and
two
wood
screws
1
in. No. 16 F.H..........................................................................
KNEE LIFTER PARTS
No.
37563
Plate
56864
20656
56865
20656
2763
20633
12242
20633
6335
20633
6336
—
2766
20633
356C
20633
2767
20633
356C
20633
6337
20633
7125
20633
356C
20633
356C
20633
2770
20633
140219C
20633
23767
20633
Name
Chain, length 15 in. with 56864 and
56865.......................................................................................
Chain Hook (large).............................................................................
"
" (small)........................................................................
Rock Shaft..........................................................................................
"
'' Hanger with two wood screws
1 in. No. 10..............................................................................
Rock Shaft Knee Arm........................................................................
Rock Shaft Knee Arm complete. Nos. 2766,
2767 and 6335.........................................................................
Rook Shaft Knee Arm Hub with 356C..............................................
"
"
»
« It Screw..........................................
“
"
" Plate with 356C.............................................
“
"
<
1 1
1
ggt Screw.........................................
"
"
Lifting
Bracket
with
two 356C
"
"
"
"
Hook..........................
“
"
"
«
« Screw
"
"
*'
"
Set
Screw....
*
" Stop Dog with 140219C...............................................
"
"
» ‘I gg^ Screw................................................
Rock Shaft complete. Nos.2763,2770,6336,
6337,7125 and two 12242.......................................................
23
MACHINE BASE
N0.
Plate
Name
131460
20657
Machine
Base...............................................................................
131019
20657
I I
" Oil Pipe...................................................................
131020
20657
N
" " " Valve..................................................................
54477
20657
I I
" Screw Stud...............................................................
51576E
20657
M
" " *' Nut....................................................................
9842
20657
n
" ” « n Washer............................................................
131279
20657
fl
Cushion (felt)................................................................
948E
20657
N
Screw, to fasten machine to base
131461
20657
Machine
Base complete. Nos. 131019,
131020, 131460, three each 9842,
51576E, 54477 and four each 948E and
131279.....................................................................................
MACHINE BASE OIL DRAIN JAR
(SWINGING TYPE)
No.
Plate
Name
131185
20658
Jar (glass)............................................................................................
131191
20658
'' Cap...............................................................................................
131188
20658
" Clamp............................................................................................
131217
—
" " 131188 with 131189...................................................................
131189
20658
" “ Lever...........................................................................................
1247C
20658
" " Hinge Screw...............................................................................
131265
20658
Nipple (long).......................................................................................
131266
20658
" (short)......................................................................................
131267
20658
" Elbow.......................................................................................
131268
20658
Machine Base Oil Drain Jar (swinging
type) complete. Nos. 131185, 131191,
131217, 131266 and two each 1247C,
131265 and 131267.................................................................
131462
20658
Machine Base with Oil Drain Jar (swing
ing type) complete. Nos. 131268,
131460,
three
each
9842,51576E,54477
and four each 948E and 131279..............................................
STILETTO
FOR NO. 147-39 MACHINE
No.
Plate
35964
20656
Name
Stiletto (for belt loop work).
