INSTALLATION DIAGRAMS: SV-6711B

SV-6711 Panel/Bumper
Locknut installation

MOUNTING SURFACE

White DOT
indicates "UP"


INSTALLATION DIAGRAMS: SV-6711H

SV-6711 Threaded
Color CCD Camera

Universal Hanging
Bracket

Set Screw holds
camera inside bracket

Set Screw holds
camera inside bracket

White DOT
indicates "UP"
