Component Testing Procedures
WARNING
To avoid risk of electrical shock, personal injury, or death, disconnect power to oven before servicing, unless
testing requires it.____________ _______________________ ____________________________________________
Illustration Component Test Procedure Results
Blr30D.-jH
ээшшвввв
ERC3 - Touchmatic
electronic range
control
FI—Shorted pad button.
F2—Oven cavity over temperature.
F3—Open circuit in oven temperature
sensor circuit.
F4—Shorted circuit in oven
temperature circuit.
F^-Defective watchdog circuit in
control.
F7—Failure of door lock switch sensing
with door locked.
F9—Failure of door lock switching
sensing with door unlocked.
DOOR—Lock status is not sensed
within 20 seconds of energizing door
lock relay.
Verify actuator operation.
Check sensor wiring, sensor, and
temperature limiter.
Check sensor resistance and wiring.
Check sensor resistance and wiring.
Replace ERC3.
Check latch switch and door motor.
Check latch switch and door motor.
Verify operation of door latch switches.
ERC3 Controlled Oven temperature
adjustment
Push BAKE pad.
Push SLEW pad until an oven
temperature greater than 500“F
displays.
Immediately push and hold BAKE pad
until "00” displays, approximately 5
seconds.
To decrease oven temperature (for a
cooler oven). Push SLEW pad until
negative numbers appear. Oven can be
adjusted from -05" to -35° lower. To
avoid over adjusting oven move
temperature -5° each time.
To increase oven temperature (for a
warmer oven), Push SLEW pad until
positive numbers appear. Oven can be
adjusted from 5* to 35° higher. To avoid
over adjusting oven move temperature
5° each time.
Push
OVEN CANCEL button.
Temperature adjustment will be
retained even through a power failure.
While increasing or decreasing oven
temperature, this does not affect self­
cleaning temperature.
ERC3 Controlled Twelve hour off Control will automatically cancel any
cooking operation and remove all relay
drives 12 hours after the last pad touch.
ERC3 Controlled Child lock out Control input features will be disabled
and display will indicate “OFP, when
BAKE and CLOCK are pushed
simultaneously and held for 5 seconds.
Control wiItVetum to normal operation
by repeating the procedure.____________
100% bake 10% broil
0% bake 100% broil HI
0% bake 93% broil 5
0% bake 87% broil 4
0% bake 80% broil 3
0% bake 73% broil 2
0% bake 67% broil 1
ERC3 Controlled Drive requirements
Based on a 60
second cycle.
Bake
Broil
Clean
Stage 1
Stage 2
Lock light
Time controlled 15 minutes 0% bake
100% broil.
Time controlled 100% bake 10% broil.
On at the start of the clean cycle.
Off at approximately 400°F ± 25°F.
RT2320003 Rev. 9 April 1999
