PRECAUTIONS:
1. Read the following precautions and
installation Instructions compietely
before beginning installation. Please
note that this system should be
Installed in accordance with local
laws and regulations.
2. This water filter Is for use on COLD
WATER ONLY, Hot water may damage
the system. Maximum temperature Is
100“F(38“ C).
3. Protect the water filter and tubing
from freezing temperatures. Failure to
do so con cause damage and void
warranty.
4. This system must be Installed on
microbloloalcallv safe woter.
START UP
1. Compare box contents with major
parts list. (See Figure 1,) Please Note;
The Filter is Installed, ready for use.
2. Install the 2 AAA batteries In the
bottom of the Filter Base assembly.
Please note how batteries are to be
installed by looking at diagram
4.
Figure 3 Figure 4
5.
molded into battery compartment.
Failure to properly install batteries can
seriously damage the system.
Remove the existing faucet aerator
by unscrewing. If the faucet aerator Is
difficult to remove, a pair of pliers with
padded Jaws may work.
(See Figures 3 & 4.)
Remove the protective foam wrap
from the diverter. Please note that
there are two gaskets provided with
the diverter. Use the thick gasket.
Thread the Diverter Valve onto the
faucet "hand-tight" only. (See Figure
5.) Do not overtlghtenl Overtighten­
ing can damage the threads. If the
diverter will not thread on properly,
use the thin gasket. If the Diverter
Valve is not compatible, an Adapter
and Gasket Kit is provided to obtain a
proper fit. (See Figure 1.)
To run water through the filter, turn on
the COLD WATER faucet and slide the
diverter mechanism. To stop the flow,
turn off the cold water faucet or slide
the diverter mechanism in the oppo­
site direction. (See Figure 6.)
Figure 5 Figure 6
