Sears Kenmore Quiet Comfort 758.144120 - Manual (Page 7)

Cleaning of Humidifier Tank
WARNING: To avoid toxic injury, fire or damage to
humidifier, use only cleaners specially recom­
mended for humidifiers. Never use flammable,
combustible or poisonous material to clean your
humidifier. To avoid scalds and damage to humidi­
fier, never put hot water in humidifier.
CAUTION: Local water purity varies from area to
area and under certain conditions water impurities
and airborne bacteria may promote the growth of
microorganisms in the reservoir of the humidifier.
To retard bacteria growth that may cause odors
and be harmful to your health, use only Sears
recommended filters. We also recommend using
32-149000 approved bacteriostat. Clean your
humidifier regularly.
Care and Maintenance
To make cleaning easier, the tank should be completely
dried out. Proceed as follows.
a. Loop switch actuator ring around plastic hook located
directly above the switch actuator.(Fig. 12)
b. Set humidity control to Constant On, air flow to High.
Run till tank is dry. ,
NOTE: With the switch actuator ring in place unit will con­
tinue to run until the ring is released. Depending upon
humidity levels, once the tank is empty the average dry
out time is approximately 2 hours.
1 .When unit is dry, release switch actuator ring and shut
the unit off.
2. Unplug humidifier, and proceed to clean._ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
WARNING: If humidifier is not unplugged, fan could
start after motor support is removed.
3. Raise lid to rest on hinges,
4. Lift out the motor support section and wipe off any
mineral deposits with a clean cloth. (Fig. 13)
CAUTION: The switch actuator is a fragile part. Set
the motor support section down carefully to be
sure the switch actuator does not become dam­
aged^_____________________________________
5. Before removing the filters, we recommend moving
the humidifier to an area where floor coverings are not
susceptible to water damage, i.e. kitchen or bath
areas.
6. Slide up the filter holders and remove (either discard
or store for further use) the filters located inside by
gently pushing out from either side. Wash off mineral
deposits on filter holder and wipe with a clean cloth.
7. Remove the floats from the bottom of the humidifier
cabinet. The cabinet should be empty and the water
reservoir is ready for cleaning. (The water reservoir is
the lower areas of the humidifier cabinef'that the
floats and filter holders are located during the normal
operation time.)
8. Proceed to “Bi-Weekly Maintenance” or “End of Sea­
son Maintenance".
Figure 12
Figure 13
