REPAIR PARTS
SEARS PORTABLE HEATER
MODEL 583.356010
KEY
NO. PART NUMBER PART DESCRIPTION
1 079437-01 Handle
2 M 50589-01 Screw (10-14 X 9/16, 2 Required) _ -
3 079424-01BF Upper Shell
4 M50834 Fan Shroud (Top)
5 M30884 Fan
6 M29750-04 Motor and Pump Assembly (Also See Page 13)
7 M50785-01 Combustion Chamber
8 M29707-03 Burner Head Assembly (Includes Keys 9-14)
9 M29824 Special Nut (14 MM)
10 M50597 Siphon Nozzle
11 M16741-18 Retaining Ring
12 M29615-01 Nozzle Adapter Bracket
13 M29835-2 Spark Plug
14 M29805 Nozzle Adapter
15 Ml6660 Photocell Bracket
16 Ml 6656-4 Photocell
17 M50833 Fan Shroud (Bottom)
18 M51061-01 Motor Mounting Bracket
19 NTC-4C Hex Torque Nut (2 Required)
20 M 29652-04' Airline (Rubber Tubing)
21 M 29652-05 Fuel Line (Rubber Tubing)
22 079423-01 BF Lower Shell
23 M11271-8 Clip Nut (6 Required)
24 Ml 0990-3 Bushing
25 M 29814-02 Fuel Filter
26 M 50570-03 T ransformer
27 M51000-01 Fuel Tank Cap
28 M51002-01 Fuel Tank Cap Gasket
29 M50671-01 Safety Control w/Reset Button and Hex Nut
30 079422-02BH Fuel Tank
31 Ml 1084-27 Screw (10-16 X 1/2, 6 Required)
32 Ml 3942-5 Wire Connector (Red Wires)
33 Ml 1084-26 Screw (10-16 X 3/8, 12 Required)
34 Ml 1143-1 Strain Relief Bushing
35 Ml 0813-81 Extension Cord
36 M50837 Fan Guard
37 M25907 Snap Bushing
38 M30865-02 Open/Closed Bushing
39 M50104-02 Shorty Bushing
40 Ml 5823-37 Screw (Grounding, 8-18 x 1/4)
41 079552-01BH Side Cover
42 Ml 3942-7 Wire Connector (Blue Wires)
43 Ml 3942-6 Wire Connector (White Wires)
44 Ml 0908-2 Screw (6-32 X 3/8, 2 Required)
45 M50631 Rubber Bumper (2 Required)
079548-02 Owner's Manual (F642-15784)
