MAINTENANCE AND TROUBLE-SHOOTING
Inspect and tighten ait parts of the CARDIO FIT at least every three months. Keep the monitor out of direct
sunlight or the LCD display may be damaged. The monitor can be cleaned using a soft, dry cloth. Do not allow
liquid to come In contact with the monitor. Remove the batteries when storing the CARDIO FIT.
REPLACING THE BATTERIES
If the display of the Monitor (1) becomes dim, the two L1154
watch batteries shouid be replaced. Remove the #8 x 1/2”
Screw (16) from the back of the Monitor. Remove the two
screws from the back cover of the Monitor and remove the
back cover. Push the two old batteries out of the clips, and
insert two new batteries.
Reattach the back cover and reattach the Monitor (1) to the
Frame (6). Make sure that the wire on the Monitor is piugged
into the sensor wire. Insert any excess wire into the Frame.
Make sure not to pinch the wire between the Frame and the
Monitor.
ADJUSTING THE MAGNET AND REED SWITCH
If the monitor does not function properly, the Magnet (27) and
Reed Switch (15) should be check^. Pivot the Pedal Frame
(7) until the Magnet is aligned with the Reed Switch. Loosen
the #8 X 3/4” Screw (18) and slide the Reed Switch toward
the Magnet until there is a 1^” gap between the Magnet and
the Reed Switch. Retighten the Screw.
LUBRICATING THE CARDIO FIT
The ends of the Link Arms (4) should be oiled every six
months. Apply a few drops of light multi-purpose oil between
the Link Arms and the dome caps in the indicated locations.
Screws
Batteries
-.-18
'^15
