PARTS LIST
KEY
NO. PART NUMBER DESCRIPTION
43 SSF-6627 Stud 3/8" - 16 Taptite (1 used - Torque 25 to 30 ft. lbs.)
44 SSF-935 Screw #8-32 x 3/8" {2 used)
45 AC-0322 Filter Plate Assennbly
* 46 AC-0333 Felt Filter
47 SSF-955 Screw3/8"-16x 1-1/2" 5 used - Torque 25 to 30 ft. lbs.)
48 CAC-4213 Head 4issembly (includes 2 ea. Key #50 & 4 ea. Key #51)
*
49 CAC-291-1 Head Gasket
■ 50 265-25 Intake Flapper Valve
0
(2 used on, head) 0
■ 51 SSF-9821 Screw, THD Forming 5-^ 10x1/4 (8 used)
52 CAC-294 Restrictor Plate (2 used)
■ 53 265-196-1 Flapper Val'tre with Corner Bevels (o
(2 used on valve plate)
54 CA04212-1 Valve Plate Assembly (includes 4 ea. Key #51 & 2 ea. Key #52 & 53)
*
55 CAC-54-2 Valve Plate Gasket
+ 56 CAC-56-1 Compression Ring (4 used)
+ 57 CAC-58 Oil Ring (4 used)
+ 58 CAC-57 Oil Ring Expander (2 used)
59 CAC-55-1 Piston (2 used)
60 265-19 Piston Pin (2 used)
61 CAC-207 Piston Pin Plug (4 used)
62 265-410 Connecting Rod /\ssembly (2 used Includes two SSF-927 screws)
63 SSF-927 Screw 1/4"-20 x 1-1/8" (2 used)
64 AC-0205 Crankcase and Cylinder
65 SST-104 Ball Bearing (2 used)
66 SSP-486 Pipe Plug, 3/8-18“ NPT (2 used)
ie 67 SSP-505 Oil Plug >
68 DAC-276 Base
*
69 265-16-1 Base Gasket
70 AC-’0203 Crankshaft
71 SSF-925 Screw 1/4 - 20 x 7/8" (8 used)
72 SSN-1018 Wavy Spring Washer
74 265-2 Flywheel
75 SSN-1014-ZN Washer
76 SSF-3039-ZN Screw
*
77 AC-0169 Oil Seal
* 78 265-6 Vent Filter
79 LA-1923 Drain Tank Label
80 AC-0330 . Solberg Filter
NOTSHOWN
•
AC-0331 Solberg Fitter Replacement
MGP-184160 Owners Manual
Parts Ordering Information
+ Key No. 56, 57,58 only available in Ring Kit KK-4313.
• Key No. 19, pressure release valve and nut is available as part of Kit KK-5020.
■ Key No. 50, 51 and 53 only available in Valve Kit KK-4275.
* Key No. 46, 49, 55, 67, 69, 77, and 78 are available in Gasket Kit K-0159.
15-Eng
