#6-3041 SNAPPERIZER KIT
3. Hook the ends of the springs over the tabs on the
bottom plate as shown. See Figure 3. After hooking the
springs on the tabs, use pliers to squeeze each hook
closed over the tab.
CLOSE ENDS WITH PLIERS
Figure 3 - Spring Connection Detaii
4. Position the bottom plate with FRONT marking
between the front wheels. See Figure 4. Hook the
ends of each spring over the nearest wheel arm
bracket. Reconnect the spark plug wire to ready the
mower for operation.
POSITION FRONT MARKING
OPERATING HINTS
Before starting the engine, raise the mower deck into
the highest cutting height (lowest notches) or in position
to allow maximum pulverizing with minimum of grass
being cut. Run engine at top speed and low ground
speed for best results. If leaf build-up is high, push
down on handies to raise deck above the pile then lower
deck slow enough to allow pulverizing without choking
the deck with leaves and stalling the engine.
CAUTION: The Snapperizer is not intended for
shredding large sticks or tree limbs. The area must be
cleared of stones, wire, large sticks or other objects,
which could jam the blade and stall the engine. If
jamming occurs, and cannot be cleared by rotating
blade with recoil starter, DISCONNECT and SECURE
SPARK PLUG WIRE, raise deck and manually rotate
blade until jamming object can be removed.
KIT PARTS LIST
ITEM PART NO. DESCRIPTION
1 5-1243 SCREEN, Fastener Assembly
2 7-2002 RING, Bottom
3 9-0223 NUT, 5/16-24 Hex (3)
4 9-0187 WASHER, 5/16 Split Lock (3)
5 1-2587 SPRING (4)
Figure 4 - Bottom Plate Marking
AIR CLEANER SERVICE NOTE: The pulverizing of dry
debris is a dusty/dirty operation. Because of this, wear a
facemask and service the air cleaner after use under
such conditions rather than waiting for normal service
interval. Also, keep grass catcher bag clean to allow for
proper air flow.
INSTRUCTION #4-6554 (REV. 1, 2/24/99)
