TABLE OF CONTENTS
Water Treatment Filter Cartridges......................... ................ .............................. 3
Planning Installation / Typical Installation Drawings / Tools and
Materials Needed . .... ....................... .................................................................. 4 ~ 5
Water Filter Housing Installation .
Using Compression Fittings -
Using Soldered Copper............
Using Threaded Fittings , ,.
Installing Filter Cartridge ,.
Filter Cartridge life / Replacement
Repair Parts............................ .........
5 - 7
5 - 6
6
7
7
8
9
WATER TREATMENT FILTER CARTRIDGES
Filter cartridges are available (not included with water-
filter housing) from Sears to remove (1) sediments, (2)
tastes and odors, (3) tastes, odors and chemical con
taminants, and (4) tastes, odors and lead.
Following is a list of filter cartridges available at the
time of tliis printing. Shop your local Sears store for
the current selection
(1) Sediment F0ter Cartridge, Sears Stock No,
42-34360 (25 micron), or Stock No. 42-34362 (5
micron): Sediment cartridges remove sand, silt, clay,
dirt, and other sediments from water The 25 micron
cartridge filters larger sediments from water, and al
lows higher flows at less pressure drop. The 5 micron
cartridge filters finer sediments from water.
Taste and Odor Cartridges: Many bad tastes and/or
odors are removed from water by an activated carbon
cartridge, It is most often used to remove chlorine taste
and smell, usually to a single faucet such as tlie kitchen
cold
Note: Small amounts of hydrogen sulfide (noticeable
as “rotten egg” odor) may be reduced by taste and
odor filters for a short time, quickly exhausting tlie car
bon media. Consult your Sears store for proper contin
uous treatment.
Sears has several taste and odor filter cartridges avail
able, These are:
(2) Sears Stock No. 42-34370: for' 9596 chlorine
reduction,
and Sears Stock No. 42-34372; for 9996 chlorine
reduction
(3) Sears Stock No. 42-34375: for 9996 chlorine
reduction, plus chemical contaminants
(4) Sears Stock No. 42-34377: for 9996 chlorine
r e d u c t i o n , 9 5 9 6 lead reduction
Locate the water filter housing on the cold water sup
ply pipe, under the kitchen and/or bathroom sink, to
filter the cold drinking water. Refer to the following
drawing.
FILTERING WATER TO ONE FAUCET
—-
xl
B
ji
!!
p p.kiichen sink
T
HOT
COLD
WATER
FILTER
HOUSING
